ROBO C2 Quick Start Manual

Hide thumbs Also See for C2:
Table of Contents

Advertisement

Quick Links

Download this manual
For a digital version of this Quick Start Guide in
EN
FR
ES
DE
IT
please visit
robo3d.com/c2-qsg
PL
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ROBO C2

Summary of Contents for ROBO C2

  • Page 1 For a digital version of this Quick Start Guide in Quick Start Guide please visit robo3d.com/c2-qsg...
  • Page 2 Welcome to the Robo family! We’re thrilled you’re here and want to extend a big thank you for choosing Robo. Whether you’re making projects for school, work, or home, this is the tool engineered to help you unlock the limitless possibilities of your creative potential.

  • Page 3: Inside The Box

    Inside the box Besides your new Robo C2, you will find the following in the box: Quick Start Guide Toolbox with Extruder Face Plate cover, 3 Allen Wrenches, Autodesk Fusion 360 design software (1 year free) Tweezers, Stylus, Lubricant, Robo Stickers and Z-Offset Tool...
  • Page 4 N USB Port 2 © 2018 Robo 3D Inc., San Diego, California. All rights reserved. Robo, Robo 3D, Robo C2, Robo R2 are trademarks or registered trademarks and are the properties of Robo 3D Inc. Registered in the USA and other countries.
  • Page 5 1. Visit robo3d.com/register to register your Robo C2. 2. Locate the SERIAL NAME to complete registration. We highly recommend registering your Robo C2 to connect your warranty with your account and to receive all the latest updates. robo3d.com/warranty See full terms and conditions of warranty at:...

  • Page 6: Initial Setup

    Step 2 Initial set-up You can also watch how to set up Robo C2: robo3d.com/c2-qsg 1. Remove the four orange protective 2. Cut four zip ties. 3. Magnetically attach Extruder Face gantry clips by pushing them over Plate to extruder assembly.
  • Page 7 Note: Use Stylus for all interactions with touchscreen. Note: Connect Robo C2 to Wi-Fi to update your printer software and to print from the Robo App, web dashboard or Chromebook. You may also connect to your network using an Ethernet cable.

  • Page 8: Update Software

    3. Screen will say UP-TO-DATE software is already updated. If not, select UPDATE and the update will begin. Always keep your Robo C2 up-to-date Follow this process regularly to confirm you are operating with the most up-to-date advancements and functionalities available.
  • Page 9 189.1°C 56.9°C Extruder 1 Options Update System 189.1°C 56.9°C Step 5 Calibration Ensure Extruder Nozzle is clean prior to starting calibration. Calibrate your Z-Offset before you start printing. Z Offset Wizard Z Offset Wizard Z Offset 1/4 Use the Z Offset Wizard to properly set the home position for the Z value of your printer.

  • Page 10: Load Filament

    1. Insert Filament Spool Holder into rear 2. Cut at least 30 cm of filament before 3. Feed filament all the way through slot of Robo C2 with the taller tab end hanging filament spool onto Filament Filament Feed Tube and then push filament first.

  • Page 11: Test Print

    Step 7 Test print 1. Select FILES. 2. Select LOCAL STORAGE. 3. Select a file to print. 4. Select START. 5. Printer will go through automatic leveling sequence, then file will begin printing. Select PAUSE to pause your print CANCEL to cancel your print at any time.
  • Page 12 Step 8 Removing a print 1. Gently lift Print Bed out of printer. 2. Flex the Print Bed from several 3. Your print should easily remove from positions to help loosen the print from Print Bed. Print Bed. 4. If the print is too difficult to remove, carefully use the spatula to gently pry it free.
  • Page 13 4 ways to control your C2 Learn more at: robo3d.com/software Prepare files and start prints using any of these custom Robo software options. Desktop Software Web Dashboard Mobile App Touchscreen Wi-Fi Wi-Fi Wi-Fi Ways to connect None or printer hotspot...
  • Page 14 Control your prints using the Robo App Download the free Robo App and easily control each print right from your Android or Apple iOS devices. Cloud storage integration Connect to your cloud storage and access all your files. Monitor print progress Watch every step of your print’s progress,...
  • Page 15 Robo C2 is connected to the internet. Connect your printer to your printer via the internet with Access the same network using the Robo C2 IP address. You can find Control. This feature can be set up through the the IP on your Robo C2 touchscreen: Robo web dashboard.
  • Page 16 Make the imagined. QSG V3...
