- Page 1 USER MANUAL Digital Audio Decoder to Analog With SPDIF/Toslink 3X1 Switcher （Model No：ADCN0001M1） Enjoy the vivid world! PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn...
- Page 2 REMARK Manufacturer does not make any commitment to update the information contained herein. Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
- Page 3 PACKAGE CONTENTS: 1、 Main unit 1pcs 2、 AC power adapter 1pcs 3、 User manual 1pcs FEATURES OF THE INTERFACE: FIG.1.0 Front Panel View IN1～3: SPDIF/Toslink input ports GREEN LEDS: input led status light (When the power off all lights are off) PWR(Red LED): Power led status light SWITCH: In the running state, fast press is switching signal source, keep press for 3 seconds is power off;...
- Page 4 OPERATIONG AND CONNECTION: 1. Connect one from digital audio signal source into any one input port of decoder. optical fiber 2. If you need a digital audio, connect one from into the output port of optical fiber digital power amplifier decoder.
- Page 5 SPECIFICATIONS: ADCN0001M1 Support audio format ………………….…….…….….….….DTS/DTS-CD/AC3/HDCD/THX/PCM/LPCM Digital input level ………………………………………………………………………………0.1~1Volts p-p L/R output level(1kHz@0dB) ……………………………………………………………………800mV RMS Headphone output power (1kHz@0dB RL=32) ………………………………………………………30mW SNR @0dB（CCIR/ARM） …………………………………………………………………………………90dB Distortion …………………………………………………………………………………………………0.1% Frequency response ……………………………………………………………………………20Hz~20KHz Max working current …………………………………………………………….……….…….….…..350mA Power adapter format Input ……..….….…….…….…….… AC 100V～240V 50HZ/60HZ; DC5V/1A Operating Temperature range ……..…………….………………………………………………-10 to +55℃...
- Page 6 FAQ: Before power on, pls check the connection line carefully. And make sure that all interfaces are normally connected. The common trouble shooting way shows below: Problem Description Solutions 1. Check if the power adaptor head is truly and correctly inserted the Non-Power-Connec power socket.
