- Page 1 Commissioning English Dallmeier DMX 800 DMX 1600 000795 / Rev. 1.0.3 / 2014-03-13...
-
Page 2: Table Of Contents
Safety Instructions ........................................3 HDD Mounting...........................................4 Mounting .............................................5 Connections ..........................................6 Login ............................................8 Dimensions ..........................................10 Validity This documentation applies to the audio and video recorder DMX 800 / DMX 1600. It has been produced on basis of software version 7.3.3. www.dallmeier.com... -
Page 3: Safety Instructions
(UPS). A sudden voltage drop can damage the RAID system. Modifications Do not make any modifications to the hardware or software that has not been tested and approved by Dallmeier. Inappropri- ate modifications can cause malfunctions, damages and data loss and can result in loss of warranty. -
Page 4: Hdd Mounting
Recorders that have been ordered without hard disk drive must be equipped with five 2.5" hard disk drives (Raid 5) at least. Note that all mounted hard disk drives must be tested and released for mounting by Dallmeier (HDD whitelist in the Partner Forum)! may not be formatted or partitioned! Mounting The hard disks should be mounted in a row , starting with the slot for HDD1 (left, lower). -
Page 5: Mounting
19’’ racks with a depth of 60 up to 120 cm. ► Ensure proper ambient conditions. ► Exclusively use the 19’’ installation rails provided by Dallmeier. ► Shorten the installation guidances (predetermined breaking point) according to the depth of the 19’’ rack if necessary. -
Page 6: Connections
AUX / Line IN Serial Interface COM 1 3.5 mm phone jack, 16 kOhm, 2.828 Vpp (for intercom) Weidmüller, 2 pins, RS485 (only for Dallmeier PTZ Dome cameras) Audio OUT 3.5 mm phone jack, 1 kOhm, 2.828 Vpp Microphone IN 3.5 mm phone jack, red, 4.3 kOhm, 2.828 Vpp (for intercom) - Page 7 Connections Contact IN Cameras (M) 17 (GND) Assignment Standard Function Contact 1 Camera 1 - Start recording Contact 3 Camera 3 - Start recording Contact 2 Camera 2 - Start recording Contact 5 Camera 5 - Start recording Contact 4 Camera 4 - Start recording 2 (GND) Contact 7...
-
Page 8: Login
In the initial state it is possible to login without password. The rights of the Administrator group are valid. Note that the definition of the passwords and of the network parameters is necessary for remote access (e. g. Dallmeier PView 7). - Page 9 IP address 192.168.2.230 (can be changed with the software IP-Finder without login) Password Serial number (e.g. DAX2-12345) Note that the definition of the passwords and of the network parameters is necessary for remote access (e. g. Dallmeier PView7). Login ►...
-
Page 10: Dimensions
Dimensions Housing 19 " Rail 19 " Holder Measures in millimetre (mm). www.dallmeier.com... - Page 11 Notes...
- Page 12 The manufacturer accepts no liability for damage to property or pecuniary damages arising due to minor de- fects of the product or documentation, e.g. print or spelling errors, and for those not caused by intention or gross negligence of the manufacturer. Dallmeier electronic GmbH & Co.KG Cranachweg 1 93051 Regensburg, Germany www.dallmeier.com...
