Summary of Contents for SOUNDMASTER URD860
- Page 1 DEUTSCH PORTUGUÊS ENGLISH NORSK FRANÇAIS SVENSK NEDERLANDS ESPAÑOL Hersteller Wörlein GmbH Tel.: +49 9103/71670 Gewerbestrasse 12 Fax.: +49 9103/716712 D 90556 Cadolzburg Email. info@woerlein.com GERMANY Web: www.woerlein.com URD860...
- Page 2 ENVIRONMENTAL PROTECTION Do not dispose of this product with the normal household waste at the end of its life cycle. Return it to a collection point for the recycling of electrical and electronic devices. This is indicated by the symbol on the product, user manual or packaging.
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS 1. READ INSTRUCTIONS - All the safety and operating instructions should be read before the appliance is operated. 2. RETAIN INSTRUCTIONS - The safety and operating instruction should be retained for future reference. 3. HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered to. 4. -
Page 4: Power Sources
POWER SOURCES Insert 2 x “AA” size batteries AC POWER cord into a wall AC POWER outlet into the battery compartment AC POWER You can power your portable system by plugging the AC power cord into the AC inlet at the back of the unit and into a wall AC power outlet. -
Page 5: Location Of Control
LOCATION OF CONTROL CD DOOR MODE/ DIMMER SKIP+ PLAY/ PAUSE/ STEREO SKIP- ON/ OFF/ FUNCTION VOLUME- / ALARM 1 PROGRAM/ SET/ EQ VOLUME +/ ALARM 2 STOP/ MEMORY+/ +10 SNOOZE/ SLEEP SPEAKER LCD DISPLAY PHONE JACK AUX IN JACK PHONE USB PORT FM ANT AC POWER CORD... -
Page 6: Basic Function
BASIC FUNCTION - Connect of power plug to a wall outlet. The appliance is now in standby mode. - Press and hold DIMMER button for around 2 second to select three stage backlight dimmer. - Press “ ” button to switch on unit. - Press “... - Page 7 CD / MP3 OPERATION GENERAL OPERATION Press to start playing CD/MP3 disc. Press again to stop playing CD/MP3 operation temporarily. Press again to resume playback. Press once to playback the current track, Press again for previous track Press for next track Press to stop CD/MP3 operation.
-
Page 8: Usb Operation
USB OPERATION Press to start playing CD/MP3 disc. Press again to stop playing CD/MP3 operation temporarily. Press again to resume playback. Press once to playback the current track, Press again for previous track Press for next track Press to stop CD/MP3 operation. Press and hold “+10”... - Page 9 OTHER OPERATION CLOCK SETTING Clock setting only available in standby mode 1. Press and hold the SET button until the system entered the clock setting mode. 2. System will enter the 12/24 hour setting & Display will flash “24H” . 3.
-
Page 10: Specifications
SPECIFICATIONS Power Supply: AC 220V-240V ~ 50Hz DC: 2 x AA Batteries (Not included) Power Consumption: 12W Output Power (RMS): 2 x 1W Unit Dimensions: 160(W) x 236.5(D) X 80.5(H) MM Unit Weight: 0.95kg Radio Tuning Frequency: FM: 87.5 -108MHz 5V DC =100mA...
