Fike FAAST XT 68-302 Installation And Maintenance Instructions

INSTALLATION AND MAINTENANCE INSTRUCTIONS
68-302 FAAST
Fire Alarm Aspiration Sensing Technology
SPECIFICATIONS
Electrical Characteristics
External Supply Voltage
Average SLC Operating Current
Power Reset
Relay Contact Ratings
Environmental Ratings
Operating Temperature
Sampled Air Temperature
Humidity
IP Rating
The purpose of this document is to provide practical information for mount-
ing and connecting to FAAST XT. For full product information, which includes
installation guidelines, instructions for safe use, and warranty and safety
information, refer to the FAAST XT Comprehensive User Guide available at
systemsensor.com/68-302userguide or by scanning the QR code.
ITEMS INCLUDED WITH UNIT
• FAAST XT (68-302) unit
• Mounting bracket and hardware
• Installation and Maintenance Instructions
• USB interface cable
• PipeIQ software, comprehensive manual, and other helpful documents
may be downloaded at systemsensor.com/faast
CONNECTING TO FAAST XT
FAAST XT requires a configuration download from PipeIQ in order to initialize.
This connection can be achieved using either the USB port located on the front of
the device, or the Ethernet port located inside the wiring cabinet.
CONNECTING TO FAAST XT VIA USB
NOTE: In order to connect your computer to the FAAST XT using a USB con-
nection, a USB driver must first be installed. The driver installation occurs
during the installation of PipeIQ version 2.0 or later. Once the driver is in-
stalled, connect to the device using the following steps.
1. Launch PipeIQ.
2. Create a new project and select FAAST XT device, or open an existing project
3. Expand the tree view in the left side navigation pane to reveal the device
4. Right click on the device and select 'Connect Device'
5. Select USB, The USB combo box should already be populated with FAAST
XT (Com Port Number).
6. Select Read only/Administrator(requires password – default is 'password')
mode Click Connect.
CONNECTING TO FAAST XT VIA ETHERNET
Default Device IP Configuration
IP Address: 192.168.1.10
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.1.1
Primary DNS: 0.0.0.0
Secondary DNS: 0.0.0.0
CONFIGURE YOUR PC
Your PC will need to be sitting on the same local area network as the FAAST XT device
in order to establish communication. Change your PC's IP address to 192.168.1.15 by:
1. Accessing your network setting in your PC's control panel
2. Open 'Local Area Connection' settings and select 'Properties'
3. Select 'Internet Protocol Version 4 (TCP/IPv4) and then select 'Properties'
FK-600-000
18 – 30 VDC
300 µA
1 sec
3.0A @ 30VDC, 0.5A @125VAC
32F (0C) to 100F (38C)
-4F (-20C) to 140F (60C)
10 to 95% non-condensing
IP30
®
4. Select 'Use the following UP address and enter 192.168.1.15. If the
subnet mask does not automatically populate, enter 255.255.255.0
into the subnet mask field.
5. Hit OK and close out of the network menus.
(Important Note: Before changing your PC's IP address, be sure to take note of
whether your IP is currently dynamically set, or is a static IP address. If your PC
is assigned a static IP address, make note of the IP address and subnet mask so
that you can change back to the proper settings after the FAAST XT is configured.)
CONNECT USING PIPEIQ
1. Launch PipeIQ. (PipeIQ may be downloaded from systemsensor.com/faast)
2. Create and save a new project, or open an existing project
3. Expand the tree view in the left side navigation pane to reveal the device
4. Right click on the device and select 'Connect Device'
5. Change the User field to 'Administrator' and enter the password – the
default password is 'password' – then hit 'Connect'
6. Upon connection, a green check will appear next to the device in the
navigation tree
INSTALLATION
This equipment must be installed in accordance with all local and national
codes and regulations.
PIPE INSTALLATION
The pipe layout is designed using the PipeIQ software package. Refer to the
Comprehensive Instruction Manual to design the pipe network. All pipe must
be installed in accordance with local and national codes and regulations. The
pipe network should be complete before proceeding with the physical and
electrical system installation.
PHYSICAL UNIT INSTALLATION
Make sure that there are no pipes or electrical wires within the wall before
drilling any mounting holes
SECURING THE MOUNTING BRACKET
The typical mounting location for the FAAST XT unit is on the wall. The unit
is mounted to the wall using the enclosed mounting plate. Figure 1 shows the
wall mounting plate. For easier access to the FAAST XT unit, it is preferred to
position the mounting plate in an easily accessible location.
1. Place the mounting bracket on the wall in the desired location and use
it as a template to locate the necessary mounting holes.
2. Mark the hole locations and remove the bracket. It is recommended to
secure the bracket using the 4 outer mounting holes.
3. Using a drill and the proper size bit for your mounting hardware, drill
the necessary holes.
4. Use appropriate fasteners to accommodate the mounting surface and
FAAST XT device weight.
5. Secure the bracket to the wall.
1
