Clas Ohlson HT388 Instruction Manual

Electric Air Pump
Art. no 31-3204 Model HT388
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services (see address
details on the back).
Safety
• The product may be used by children of 8 years and older
and by persons with reduced physical, sensory or mental
capability or lack of experience and knowledge provided
they have been given supervision or instruction concerning
use of the product in a safe way and understand
the hazards involved.
• Never let children play with the product.
• Cleaning and user maintenance must not be performed by
children without adult supervision.
• If the mains lead has been damaged, it must only be
replaced by the manufacturer, authorised service facility or
qualified tradesman. This is to prevent the risk of electric
shock or fire.
• The product is only intended for personal domestic use and
only in the manner described in this instruction manual.
• The product is intended for indoor use only.
• Do not expose the product to rain or prolonged sunlight.
• Never immerse the product or the mains lead in water or
other liquid.
• The product should only be connected to a 230 V AC,
50 Hz electrical outlet.
• Never use the product if it is in any way damaged or not
working properly or if the mains lead or plug is damaged.
Do not use the product if you have dropped it on the floor
or into water or other liquid.
• Never use the product if your hands are moist or wet.
• Always unplug the product from the wall socket when it is
not in use.
• Do not use the product for longer than ten minutes at
a time. Let it cool down before using it again.
UNITED KINGDOM • customer service tel: 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk
postal Clas Ohlson Ltd, Aquilla House (First floor), 1 Becketts Wharf, Lower Teddington Road, Hampton Wick, Kingston Upon Thames, KT1 4ER
• Make sure that no unwanted objects are sucked into the air
intake while pumping.
• Never point the air outlet nozzle towards your eyes or other
people while the product is operating.
• Never try to open the housing, repair or modify the product
in any way.
• Repairs must only be carried out by qualified service
technicians and only using original spare parts.
Instructions for use
Important
• This electric air pump is only designed for the inflation of
fairly large inflatable objects such as inflatable mattresses,
inflatable pools and floating leisure products. The pump is
not intended for the inflation of small objects such as
car/cycle tyres and footballs.
• Never block the air inlet or outlet while the pump
is operating.
Inflating
1. Connect the air hose to
the air outlet (marked
INFLATE).
2. Fit a nozzle suitable for
the product to be inflated
to the end of the air hose.
3. Plug the pump into a wall
socket.
4. Switch the pump on.
Deflating
1. Connect the air hose
to the air inlet (marked
DEFLATE).
2. Fit a nozzle suitable for
the product to be deflated
to the end of the air hose.
3. Insert the plug into a wall
socket.
4. Switch the pump on.
Care and maintenance
• Unplug the pump from the wall socket before wiping it
clean with a dry cloth.
• Unplug the pump from the wall socket and store it in a dry,
dust-free environment out of the reach of children whenever
it is not to be used for an extended period.
Responsible disposal
This symbol indicates that the product should not
be disposed of with general household waste. This
applies throughout the entire EU. In order to prevent
any harm to the environment or health hazards
caused by incorrect waste disposal, the product
must be handed in for recycling so that the material
can be disposed of in a responsible manner. When recycling
your product, take it to your local collection facility or contact
the place of purchase. They will ensure that the product is
disposed of in an environmentally sound manner.
Specifications
Rated voltage 220–240 V AC, 50 Hz
Power 300 W
