Lowrance SIMRAD StructureScan 3D Installation Manual page 2

Power
Power controlled by External Switch
Black
Red
Yellow
Switch
Blue
+ _
(n/c)
12 / 24 V DC
TRANSDUCER1 TRANSDUCER2
Connectors and LEDs
ID CONNECTORS
1
2
1 Ethernet
2 Power
TRANSDUCER1 TRANSDUCER2
3 3
Structure Scan
3
3D transducer
Power controlled by Multi-Function Display
To Multi-Function
Display
Black
Black
Red
Yellow Red
Blue Yellow
(n/c)
Blue
(n/c)
Power
+ _
Control bus
12 / 24 V DC
TRANSDUCER1
LEDs
OFF No connection
ON/FLASHING - Green Connected and ok
OFF No power
ON - Red System starting
ON - Green System operating
Software error - restart
FLASHING Red/Green
unit
OFF Sounder not operating
FLASHING (every second) - Searching for bottom
Green signal
Operational system with
ON
bottom signal detected
Wiring example
4G Radar
TRANSDUCER2
Transducer connection
StructureScan® 3D Transducer cable 1
Transducer 1 Connector
Multi-Function Displays
StructureScan® 3D Module
TRANSDUCER1 TRANSDUCER2
StructureScan® 3D Transducer
TRANSDUCER1 TRANSDUCER2
StructureScan® 3D Transducer cable 2
to to
Transducer 2 Connector
Ensure both StructureScan® 3D transducer cables
are connected to the StructureScan® 3D Module correctly
12/24 V DC
