SEON SF Series Installation Manual

Service and Warranty
If your SF or SG Series CCTV Camera is to be returned to Seon Design for
service, please call toll free 877-630-7366, or 604-524-6437 and ask for a
Return Authorization (RA) number.
Technicians to better track your product when it comes in for service. Please
show the RA number on the outside of the package. ANY PRODUCT SENT
TO SEON DESIGN WITHOUTAN RA NUMBER MAY BE REFUSED.
Please refer to the Warranty form provided with your product to review the
terms of warranty service, contact and shipping information, as well as other
important issues regarding the service and operation of your product.
FCC Statement (U.S.A.)
This device complies with Part 15
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Industry Canada Notice
This Class B digital apparatus meets all requirements of the
Interference-Causing Equipment Regulations.
Cet appareil numérique de la
Règlement sur la matériel brouilleur du Canada
Information in this guide is subject to change without prior notice.
© 2004 Seon Design Inc.
All rights reserved.
1
Cut a 2 / -2 / " (52-54 mm)
1
diameter hole through the
mounting surface
An RA number allows the Service
of the FCC Rules . Operation is subject to
classe B respecte toutes les exigences du
.
www.seon.com
Document Part Number: 700-0012-02
Installing the SF Series Flush Mount Camera
1
16 8
.
Mounting screws (3)
SF & SG Series CCTV Cameras
Installation Guide
Canadian
Camera assembly
2
SG Series
Surface Mount Camera
SF Series
Flush Mount Camera
3
Connect the video/power
cable to a video monitor and
a 12 VDC power supply.
Mounting surface
Use the mounting screws to
attach the camera assembly
to the mounting surface.
Video/power cable
Green: Video +
White: Video –
Red: +12 VDC
Black: 0 VDC
