Lucci LEDlux 229150 Installation Instructions

Installation Instructions
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this product. Please keep instructions for future reference.

Warranty

• This luminaire is covered by a 3-year warranty valid for in-store replacement or refund only.
• The warranty period starts from the date of purchase. Please retain the proof of purchase.
• The warranty is for the luminaire only and does not include the rechargeable battery.
• Warranty will be void if there is any damage due to improper usage or modification to the luminaire.
• Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void the
warranty.

Installation Requirements

• Select a suitable location for installation:
−
Ensure it is on a flat and stable surface.
−
Do not place flammable material near or over the luminaire.
−
This luminaire is protected against water penetration to IP54 standards, which is splashing water from any
direction.
NOTE: The clear plastic door covering the USB ports and the power display screen and button, must
be closed and locked into position to maintain the IP54 rating.
• The luminaire must not be used if the protective shield or shade has been cracked or damaged. Replace the
protective shield or shade before using the luminaire.
• Lay out all the components on a smooth surface and make sure no components are missing before assembling.
If parts are missing, return the complete product to the place of purchase for inspection or replacement.
• Check whether the luminaire has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.

Operation Directions

1. Remove all packaging material from the product and be careful not to throw away accessories that may be hidden
within the packaging material. (Fig. A)
2. Use the ON/OFF button to operate the luminaire and set the desired lighting level. (Fig. B)
When the luminaire is off:
- Press the ON/OFF button once to turn the luminaire on low.
- Press the ON/OFF button 2 times for the medium setting.
- Press the ON/OFF button 3 times for the high setting.
- Press the ON/OFF button 4 times to turn off again.
3. Open the clear plastic door to access the power display screen and button. (Fig. B)
Press the power display button to show the remaining battery level in the luminaire.
4. Open the clear plastic door to access the USB ports at the back of the luminaire. (Fig. B & C) Insert the included USB
cable into the micro-USB port and connect the USB cable to a computer/laptop or power adaptor to charge the
luminaire. It will take approximately 5 hours to be fully charged. The power display screen will flash while charging.
When the power display screen has reached 100, the battery is fully charged.
NOTE: Please ensure an appropriate power adaptor is used to charge the luminaire.
The rated input is 5VDC, 1A.
1 | P a g e
ULTRA LED PORTABLE RECHARGEABLE LIGHT
Rated Voltage 3.7V DC, 10W
SKU# 229150
v 1 . 0 ( 0 7 / 2 0 2 0 )
