Lucci LEDlux 220822, 220823 Installation Instructions

Installation Instructions
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this product. Please keep instructions for future reference.
NOTE: This installation instruction applies to the 12V side of the fitting only.
This fitting is 12V extra-low voltage and can be DIY.
Do not plug this fitting directly into 240V.
When working with 240V, a licensed electrician is required.
The Lucci wiring kit (SKU# 220826, 220827), Lucci transformer (SKU# 220818, 220819, 220829) are sold
separately.

Warranty

•
This light fitting is covered by a 3 year warranty from the date of purchase. Please retain proof of purchase.
•
Warranty will be void if there is any damage due to improper usage or modification to the fitting.
•
Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void warranty.
•
Warranty will be void if the cabling is installed underground without suitable protection from water or damp conditions.

Installation Requirements

•
Select a suitable location for installation:
− This fitting is protected against water penetration to IP65 standards, which is jets of water from any direction.
− This fitting is designed for in ground installation only. Not suitable for installation into the ceiling.
− The cabling is not suitable for underground installation without protection from water or damp conditions.
The cabling is not designed to be immersed in water.
− This fitting, quick connectors, Lucci wiring kit (sold separately) and Lucci transformer (sold separately) are not
designed to be immersed in water. Ensure the installation area has adequate drainage so water does not pool
around the fitting, parts and accessories.
−
This fitting can be used where normally flammable materials, including building insulation, are or maybe
present, but cannot be abutted against any material and cannot be covered in normal use.
−
Take note of the clearance values. Do not remove any structural members for the installation of this product.
RISK OF FIRE – BUILDING INSULATION MUST NOT COVER THIS LUMINAIRE
Note: HCB-Height clearance to building element
SCB-Side clearance to building element
•
Do not exceed the maximum wattage rating.
•
Take care not to pull any electrical wires during unpacking as this may damage the connection.
•
Lay out all the components on a smooth surface and make sure there are no components missing before
assembling. If parts are missing, return the complete product to the place of purchase for inspection or
replacement.
•
Check whether the fitting has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
•
Ensure power to the circuit you are working on has been switched OFF before commencing any electrical work.
1 | P a g e
LED GROUND LIGHT
SKU# 220822, 220823
Rated Voltage 12V AC/DC
HCB = 10mm MIC = 10mm SCB = 10mm SCI = 10mm
MIC-Minimum insulation clearance
SCI-Side clearance to insulation
v 2 . 0 ( 0 3 / 2 0 1 8 )
