Lumascape Vestalux V2 LS9016 Installation Instructions Manual

Vestalux V2
LS9016
Product Warranty is void if product is not installed as per installation
instructions and in compliance with all local and provincial codes.
NO POWER KEEP AWAY FROM DO NOT USE SILICONE
TOOLS FLAMMABLE MATERIAL ON OUTSIDE SURFACE
READ ALL SAFETY INSTRUCTIONS FIRST
› Follow all safety instructions carefully. Failure to do so will
void warranty.
› Ensure installation complies with local electrical rules and
regulations.
› Input voltage range 30-48 Vdc.
› Only use Lumascape power supply, control equipment and
leader cables.
› Ensure mains input power is surge protected.
› Never make connections while the power is connected.
ASIA PACIFIC 18 Brandl Street, Eight Mile Plains, QLD 4113, Australia P: +61 7 3854 5000 | F: +61 7 3854 5001 | E: sales@lumascape.com |
NORTH AMERICA 1940 Diamond Street, San Marcos, CA 92078, USA P: +1 650 595 5862 | F: +1 650 595 5820 | E: info@lumascape.com |
INSTALLATION INSTRUCTIONS
FACADE OUTLINER
KEEP ELECTRONICS FREE DO NOT HOSE OR
FROM DIRECT AND MOISTURE PRESSURE CLEAN
› Do not make modifications or alter the product.
› Keep lminaire clean and free of debris.
› Only clean with warm water.
› Do not use chemicals or abrasives to clean luminaire as this may
void the product warranty.
› Connectors are to be kept clean and dry at all times.
› Once installed, all connectors are to be mated and a terminating
plug is required on the last fitting of run.
Products and specifications are subject to change without notice.
DO NOT USE CHEMICALS
OR ABRASIVES
A
A+
A++
lumascape.com.au
lumascape.com
IN0184-200717 1 /8
