III. Buttons and Indicators Function:
1. Sparkling Water Dispense/Reset Button: After selecting the desired sparkling level on
the display, press and hold the large green button to dispense sparkling water. If the
green light is flashing, a reset is required. Follow the instructions in the
Troubleshooting section.
2. Sparkling Level Decrease Button: Press the button once and the sparkling level will
decrease one level as represented by the bars on the display
3. Sparkling Level Increase Button: Press the button once and the sparkling level will
increase one level as represented by the bars on the display
4. Cooling Status Indicator: When the dispenser is in the process of cooling water, the
indicator will flash repeatedly. When it has finished cooling, the image will remain
steady, indicating that the water is at its coldest temperature
5. Replace CO
light will flash, indicating that it is time to replace the cylinder
6. Time to Clean: When the dispenser is due to be cleaned, the button will illuminate.
After cleaning, press and hold the button to reset the cleaning schedule. The light
will turn off until the dispenser is due again for cleaning.
7. Child Safety and Hot Water Dispense Button: To dispense hot water, press and hold
the child safety button and hot water button at the same time. To stop dispensing,
release the buttons.
8. Cold Water Dispense Button: To dispense cold water, press and hold the cold water
button. To stop dispensing, release the button.
IV. . Setup Procedure:
1. DO NOT PLUG THE DISPENSER IN. Invert a 3 or 5 gallon bottle water onto the
no-spill adapter. Bubbles will form in the bottle indicating that water is flowing into the
reservoirs.
2. Verify that the red HOT SWITCH on the back of the dispenser is in the off position.
Once the formation of bubbles stops, plug the power cord into an electrical outlet to
supply power.
3. Place a large cup under the spigot. Press and hold the SPARKLING WATER button until
water flows out. This indicates that the sparkling reservoir is filled. (NOTE: This
water will not be carbonated)
4. Press and hold both the CHILD SAFETY and HOT WATER buttons at the same time until
water flows out. This indicates that the hot reservoir is filled.
5. You may now turn on the red HOT SWITCH on the back of the dispenser to begin heating
the water.

6. Install a CO2 cylinder:

a) Remove the drip tray. Then lift and pull out the lower panel.
b) Turn the funnel upward for easier access. Insert the cylinder into the funnel, and
rotate clockwise to install. An audible beep will be heard, indicating that gas is
entering the dispenser. Continue to turn the cylinder firmly until fully tight.
c) Turn the funnel downward until the cylinder rests against the back wall
d) Replace the lower panel and drip tray
7. Press and hold the sparkling water button until sparkling water continuously dispenses.
: When the pressure inside CO2 cylinder drops due to low gas, an orange
