LG WK Series Owner's Manual page 21

Cabinet Installation
Open the window. Mark a line on the center of the
1
window stool between the side window stop
moldings.
Loosely attach the sill bracket to the support
bracket using the carriage bolt and the lock nut.
Attach the sill bracket to the window sill using the
2
screws (Type B).
Carefully place the cabinet on the window stool
and align the center mark on the bottom front with
the center line marked window stool.
Using the M-screw and the lock nut, attach the
3
support bracket to the cabinet track hole. Use the first
track hole after the sill bracket on the outer edge of
the window sill. Tighten the carriage bolt and the lock
nut. Be sure the cabinet slants outward.
CAUTION: Do not drill a hole in the bottom pan.
The unit is designed to operate with
approximately 12.7mm of water in bottom pan.
Pull the bottom window sash down behind the Top
4
retainer bar until they meet.
NOTICE
1. Do not pull the window sash down so tightly
that the movement of Frame curtain is restricted.
Attach the cabinet to the window stool by driving
the screws (Type B) through the cabinet into
window stool.
2. The cabinet should be installed with a very slight
tilt downward toward the outside.
Sill
Bracket
3
Carriage
Bolt
9
Cabinet
Track hole
Support
Bracket
2
Carriage bolt
and lock nut
Upper
Guide
11
Hardware Installation
Support
Bracket
2
4
Lock nut
Fig. 1
Machine screw(Type D)
and lock nut
Outer edge
of window
sill
(Type B)
6
Sill bracket
3
Fig. 2
Fig. 3
Fig. 4
Owner's Manual 21
