INNOHOME
STOVE GUARD
SGK5010
I N S TA L L AT I O N
A N D O P E R AT I N G
I N S T R U C T I O N S
1
INSTALLATION P. 4–13
For indoor use only.
Do not use in a professional kitchen.
The Control Unit must be installed
by an authorised electrician.
2
USER GUIDE P. 14–21
3
TECHNICAL SPECIFICATIONS
P. 22–24
Advertisement
Table of Contents
Related Manuals for Innohome Stove Guard SGK5010
Summary of Contents for Innohome Stove Guard SGK5010
- Page 1 INNOHOME STOVE GUARD SGK5010 I N S TA L L AT I O N A N D O P E R AT I N G I N S T R U C T I O N S INSTALLATION P. 4–13 USER GUIDE P.
- Page 2 There is a risk of explosion. The operating instructions, accessories and stickers must accompany the product. Follow the safety guidance for safe use of Stove Guard. If you have questions about the product, ask a specialist or refer to innohome.com...
-
Page 3: Table Of Contents
P. 10-11 Installation of the Control Unit Function test USER GUIDE 14–21 Getting started with Innohome Stove Guard Read before using Innohome Stove Guard 16–17 Avoiding false alarms After alarm: Cookers with mechanical controls After alarm: Cookers with touch controls... -
Page 4: Installation
INSTALLATION Installing the Stove Guard To install correctly, follow the instructions. STEP 1: STEP 2: STEP 3: Installation of Installation of Function test the Heat Sensor the Control Unit p. 5–11 p. 12 p. 13... -
Page 5: Installation Of The Heat Sensor
INSTALLATION OF THE HEAT SENSOR The recommended place to install the Heat Sensor is directly above the centre of the cooker, under the cooker hood. The Heat Sensor can also be mounted on a wall with a mounting bracket or on the ceiling. Follow these instructions for correct installation. - Page 6 COOKER HOOD Measure distance Select the mounting location Mount the Heat Sensor Measure the installation height. The Heat Sensor should be centred If there is a metal mesh grease above the cooker, preferably within Zone 1 (see the diagram below). filter on the cooker hood, make It can be attached to the grease filter.
- Page 7 I N S TA L L AT I O N U N D E R CO O K E R H O O D Allow the Heat Sensor to reach room temperature before use. The power to the cooker must be switched off (at the consumer unit). See the table below for the mounting location and follow instructions 1–4.
- Page 8 WALL 80 cm Select the required location and mount the bracket Mount the Heat Sensor Wall mounting requires a bracket (SAI1000-FBx), sold separately. The Press at least for a minute while bracket is fastened on the wall using adhesive tape or screws. attaching adhesive.
-
Page 9: Wall Mounting
WA L L M O U N T I N G W I T H B R A C K E T Allow the Heat Sensor to reach room temperature before use. The power to the cooker must be switched off (at the consumer unit). See the table below for the mounting location and follow instructions 1–5. - Page 10 CEILING Measure distance Replace lens Finding the mounting Mount the Heat Sensor position Carefully lift the lens with a Make sure that ceiling is grease- screwdriver. Press down the less and dry. Press at least for a Measure the distance between IR lens extension (included) minute while attaching adhesive.
-
Page 11: Ceiling Mounting
C E I L I N G M O U N T I N G W I T H I R L E N S E X T E N S I O N Allow the Heat Sensor to reach room temperature before use. The power to the cooker must be switched off (at the consumer unit). -
Page 12: Installation Of The Control Unit
CONTROL UNIT It is a statutory requirement that the Control Unit is installed by an authorized electrician. The power to the cooker must be disconnected throughout the entire installation. POWER Disconnect the power Switch off the power at the consumer unit. Do not turn on the Note! Consumer unit before the Heat... -
Page 13: Function Test
FUNCTION TEST The installation is completed when the test has been passed. The Heat Sensor will then give an alarm. This user manual, accessories and stickers should be left with the product for future reference. POWER Return the power Perform function test Reset the alarm Switch on the power at the Wait 30 seconds after switching... -
Page 14: User Guide
USER GUIDE... -
Page 15: Getting Started With Innohome Stove Guard
GETTING STARTED The cooker is ready for use 15 minutes after completing the installation of the Stove Guard. However, at the beginning, it may start to signal during normal cooking. This is because the Heat Sensor learns what the normal temperature ranges are during cooking. The Heat Sensor may start Press the button to indicate that The Heat Sensor has then learned... -
Page 16: Read Before Using Innohome Stove Guard
READ BEFORE Avoiding false alarms Use a pan that covers the entire hotplate to prevent false alarms. Using a lid is recommended. Always use the cooker hood if you have one. If you have a freestanding cooker or an oven under the hob, the oven controls must also be turned off once the power supply to the cooker or hob has been switched off by the alarm. -
Page 17: Action In The Event Of An Alarm
Action in the event of an alarm The cooker will automatically be ready for use after the Stove Guard has detected that the hazardous situation is over, and all the controls are set to “0”. See the alarm overview below for actions. SOUND MEANING MEASURES... -
Page 18: Other Settings
OTHER SETTINGS Change the sensitivity level Due to differences in kitchen environments, the sensitivity level of the Heat Sensor may have to be set manually. 1. Remove the Sensor from the installation plate The Heat Sensor emits 4 “beeps” ( ). -
Page 19: Checking The Sensitivity Level
Checking the Reset the Heat Sensor sensitivity level to factory settings 1. Remove the Sensor from the Remove the Sensor from the installation plate. (The Sensor installation plate. (The Sensor gives gives 4 “beeps” ( ) and the 4 “beeps” ( ) power is cut off cooker is switched off.) to the cooker). -
Page 20: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS 1. I cannot turn on the cooker, and there is no malfunction of the Control Unit. signal from the Control Unit Make sure that the Heat Sensor is firmly ANSWER 2: The Heat Sensor has been removed or attached to the installation plate and that it is posi- ANSWER 1: placed incorrectly on the installation plate. - Page 21 situations into account, including high-temperature Auto-diagnostics. cooking, and should not give an alarm too easily. The test is recommended when retrofitting the Note! Therefore, the Stove Guard only emits an alarm when cooker and ceiling-mounted Heat Sensor. a certain temperature (or rate of temperature rise) 11.
-
Page 22: Technical Specifications
TECHNICAL SPECIFICATIONS • Alarm signal 80 dB(A) @ 1 m • RF 433 MHz • Patented EP1861839, EP2902710 • Fulfils EN 50615:2015 Standard for stove guards (Eurofins Expert Services Oy) THE HEAT SENSOR Signal LED should face towards use IR lens (Lens extension for high installations) Button... -
Page 23: Warranty
4.4.2 Blocking. normal household waste. For proper handling and Signed for and on behalf of Innohome Oy: recycling, this product must be delivered to a separate collection point where it will be accepted free of charge. -
Page 24: Cooker Connection
Stove Guard supply. The circuit breaker shall have capability of interrupting the supply current within 100 ms at 4 x load. Designed and manufactured in the EU INNOHOME OY Itsehallintokuja 4 Polaris Business Park, Castor House FI-02600 Espoo, Finland...
