Ozone Subzero V1 Quick Manual

checking BRidles and speed system foR stRetch oR shRinkage
We recommend you regularly check your kites bridles and speed system to keep your kite flying
at top performance. use the measurements on the next page to check your bridle lengths.
Recommendations
• Open your kite in a large space, big enough to spread your kite out fully.
• Use a tape measure to measure the bridles as in the image.
• Print out the sheet and write down any differences.
If your bridles are out by more than 15mm we recommend replacing them, please
get in touch with the shop/dealer you purchased the kite from and they can order
individual bridle lines or a full set if they do not already have stock.
measure bridles
speed system ZeRo position
You can check your Speed System lines by levelling the front and back line
pigtails, then tension the three top ends of the Speed System where the
bridle lines are attached, they should be at the same level + or - 15mm.
See picture below.
If the difference between the three ends is bigger than 15mm you should
replace your Speed System.
if difference bigger
align
than 15mm, replace
speedsystem
