KNOW YOUR PRODUCT
V-TWIN AIR
COMPRESSOR
• 3.0HP, 50L TANK
• 164L/MIN FREE
AIR DELIVERY
• DUAL PRESSURE
GAUGES
• 2 AIR OUTLETS
INSTRUCTION MANUAL
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
1015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FBACVT-5030 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Full Boar FBACVT-5030

Summary of Contents for Full Boar FBACVT-5030

  • Page 1 KNOW YOUR PRODUCT V-TWIN AIR COMPRESSOR • 3.0HP, 50L TANK • 164L/MIN FREE AIR DELIVERY • DUAL PRESSURE GAUGES • 2 AIR OUTLETS INSTRUCTION MANUAL WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.

  • Page 2: Know Your Product

    SPECIFICATIONS - MODEL NO. FBACVT-5030 Mains Voltage: 230-240V ~ 50Hz Input Power: 2200W (3HP) No Load Speed: 2850 /min Free Air Delivery (FAD): 164 l/min Tank Volume: 50 l Max. Working Pressure: 10 bar (145 psi) Oil: SAE 15W/40 IP Rating...
  • Page 3 KNOW YOUR PRODUCT (cont.) 1. Overload Switch 11. Oil Drainage Screw / Oil level window 2. Intake Air Filter 12. Regulated Output Pressure Gauge 3. Motor Housing 13. Quick-lock Coupling (regulated 4. Pressure Tank compressed air) 5. Wheels 14. Pressure Regulator 6.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS............Page 02 KNOW YOUR PRODUCT........Page 02 INTRODUCTION............Page 05 SAFETY INSTRUCTIONS........Page 05 ASSEMBLY..............Page 10 OPERATION............... Page 13 MAINTENANCE............Page 15 TROUBLE SHOOTING..........Page 17 DESCRIPTION OF SYMBOLS........ Page 18 CONTENTS..............Page 18 WARRANTY..............Page 20...

  • Page 5: Introduction

    The electric motor has been designed for 230V and 240V only. Always check that the power supply corresponds to the voltage on the rating plate. Note: The supply of 230V and 240V on Full Boar tools are interchangeable for Australia and New Zealand.
  • Page 6 GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read all safety warnings and instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term "Power Tool" in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool.
  • Page 7 GENERAL POWER TOOL SAFETY WARNINGS (cont.) d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
  • Page 8 AIR COMPRESSOR SAFETY WARNINGS This appliance is not intended for use by young or infirm persons unless supervised by a responsible person to ensure that they can use the appliance safely. Young children should be supervised to ensure that they do not play with the appliance. WARNING! Before connecting a tool to a power source (mains switch power point receptacle, outlet, etc.) be sure that the voltage supply is the same as that specified on the nameplate of the tool.
  • Page 9 AIR COMPRESSOR SAFETY WARNINGS (cont.) ¥ Pull the ring on the safety valve daily to ensure that it operating properly and to clear any possible debris from the outlet. ¥ Keep the compressor at least 300mm from the nearest wall to ensure adequate ventilation for cooling purposes.
  • Page 10 ASSEMBLY KNOW YOUR PRODUCT WARNING! During assembly ensure the air compressor is switched OFF and disconnected from the power supply. Pre setup checks Examine the machine for signs of transit damage. If there are any signs of damage, please contact the Customer Support on: Australia 1800 069 486 New Zealand 0508 069 486 ¥...
  • Page 11 KNOW YOUR PRODUCT ASSEMBLY (cont.) Fitting the wheels (5) (Fig. 1): 1. Place the bolt through one wheel and then a washer. Now through the hole in the wheel bracket, below the tank. 2. Fasten the wheel bolt in position with a washer, spring washer and nut.

  • Page 12: Assembly

    ASSEMBLY (cont.) Assembly of the intake air filter (2) (Fig. 4): The intake air filters should come pre assembled. However if assembly is needed follow the instructions below. 1. First place the foam pad into the recess in the lower half. Then place the cover onto the lower section.

  • Page 13: Operation

    OPERATION WARNING! This air compressor must be used with a residual current device with a rated residual current of 30mA or less. Switching ON/OFF. 1. To switch the compressor On, pull up the switch (10) (Fig. 6). Fig. 6 2. To switch the compressor Off, press the switch down (Fig. 7). Note: The compressor will automatically cut off when the tank pressure reaches 10 bar and will automatically start when the tank pressure drops to 8 bar.
  • Page 14 OPERATION (cont.) KNOW YOUR PRODUCT WARNING! Wear safety glasses and ear protection. Keep your face away from the safety valve when carrying out this check. Air will be discharged at a high pressure. Checking the safety relief valve (16) 1. Check that the safety relief valve is in working order before every use.

  • Page 15: Maintenance

    MAINTENANCE IMPORTANT! Before cleaning your air compressor or carrying out any maintenance procedure, make sure that it is disconnected from the power supply to prevent accidental starting. Cleaning • Keep the safety devices free of dirt and dust as much as possible. Wipe the equipment with a clean cloth or blow it with compressed air at low pressure.
  • Page 16 MAINTENANCE (cont.) Changing the oil 1. Switch off the compressor and pull the mains plug out of the socket. 2. After releasing any air pressure, you can unscrew the oil drainage screw (11) from the compressor pump (Fig. 13). Note: To prevent the oil from running out in an uncontrolled manner, hold a funnel under the opening and collect the oil in a vessel.

  • Page 17: Trouble Shooting

    TROUBLE SHOOTING Symptom Possible Cause Suggested Solution The compressor does not Compressor has reached Compressor will start cut-out pressure automatically start once below the cut-in pressure No power supply Check the power supply, the power plug and the socket-outlet. Insufficient supply power Reduce length of extension lead.

  • Page 18: Description Of Symbols

    Ingress protection from water Litres Pressure rating Warning! The equipment is remote-controlled and may start-up without warning. CONTENTS 1x FBACVT-5030 Air Compressor 2x Air Filter 2x Wheels 2x Rubber Support Feet 2x Wheel Bolt 2x Support Feet Fasteners 2x Wheel Fasteners and Washers...

  • Page 20: Warranty

    WARRANTY YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS WAREHOUSE (see www.bunnings.com.au or www.bunnings.co.nz for store locations) WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE: Australia 1800 069 486 New Zealand 0508 069 486...
