GETTING STARTED

Setting Up Your VT 9112
6. The original dialling mode is set to TONE.
1. Choose an area near an electrical outlet
If you have tone dialling, retain the setting
and a telephone wall jack.
as TONE. If you have only rotary service
2. Connect the telephone line cord. Insert
on your phone line, you may refer to "HOW
one end of the telephone line cord into
TO SET TONE/PULSE DIALLING" section
the jack at the rear of the base unit. Plug
the other end into a telephone wall jack.
to set your phone to PULSE mode.
Make sure the plugs snap securely into
7. CHECK FOR A DIAL TONE.
place.
battery pack is charged, raise the Base Unit
3. Plug the AC power adapter into an
Antenna to an upright position. Then, pick
electrical outlet and the DC connector to
up the Handset and press PHONE key. The
the back of the base unit.
CAUTION:Use only the AC adapter shipped IN USE LED (on the Base Unit) and the
with your VT 9112. This is a Class
PHONE key (on the Handset) will light up,
2 A C a d a p t e r, s p e c i f i c a l l y
and you should hear a dial tone. If not, see
designed for use with the VT 9112
NOTE: Connect power to the base unit
IN CASE OF DIFFICULTY.
before placing the handset in the
CAUTION:
cradle.
1. Never install telephone wiring during a
4.
Set the VOLUME switch to HIGH, MID or
lightning storm.
LOW on the Handset Unit.
2. Never install telephone jacks in wet
5. CHARGE THE HANDSET BATTERIES
locations unless the jack is specifically
BEFORE USE. The battery pack
designed for wet locations.
recharges automatically whenever the
3. Never touch uninsulated telephone wires
handset is in the base unit cradle. The
or terminals unless the telephone line has
battery pack should be charged for 24
been disconnected at the network
hours before using your phone for the first
interface.
time.
4. Use caution when installing or modifying
telephone lines.
5
HANDSET FEATURES
LCD DISPLAY
VOLUME SWITCH
PHONE KEY
TONE/ KEY
PROG/MENU KEY
HANDSET INDICATORS
LCD
CHAN 3 CHANNEL INDICATION (channel = 3)
MEM 5 MEMORY INDICATION (memory no. 5)
-STORED- PROGRAM STORED INDICATION
-LINE USED- LINE-IN-USE INDICATION
SET DIAL Set Tone / Pulse Mode
8ELL 2 RINGER TYPE INDICATION (ringer type is 2)
8ELL OFF RINGER TYPE INDICATION (ringer is off)
0-00-01 CALL TIMER (at 0hr 0min 1sec)
6-59-59 CALL TIMER (at 6hr 59min 59sec)
123p5678 Phone number indication (where P= pause)
CALL TIMER IS ACTIVE
CALL TIME
TONE DIAL MODE
TONE
PULSE
PULSE DIAL MODE
BATTERY LEVEL INDICATOR(Full)
BATTERY LEVEL INDICATOR(Normal)
BATTERY LEVEL INDICATOR(Low)
7
BASIC OPERATIONS
CHARGING
IN USE
POWER
PAGE
VT9112
BASE INDICATORS
LED LED status
POWER ON
IN USE ON
Flash Ringing (incoming call is present.)
CHARGING ON Handset is on cradle for charging.
FLASH
SPARE BATT ON Spare battery is present and being charged.
FUNCTION KEYS
Button Description
PAGE To page the handset.
HOW TO SET TONE/PULSE DIALING
* Press PROG for 3 times on handset. Observe that the LCD displays:
TONE or PULSE icon and a
SET DIAL prompt.
* Press 1 to select TONE or 2 to select PULSE. Then press MEM to save the mode setting.
Press OFF to discard change.
9
The Wall Mount adaptor is designed to fit
on standard Wall Mount plates. If you are
using such a plate, you should start with
AC ELECTRICAL
OUTLET
Step #2 below.
1.Choose a spot near an electrical outlet
and a telephone jack.Your phone
requires a modular telephone jack and
TELEPHONE
a standard electrical outlet (120V AC).
WALL JACK
The power cord is six feet long; make
sure there is an electrical outlet within
reach of the base. The outlet should not
be controlled by a wall switch. If the
switch is ever turned off, the phone will
not operate.
2.Position the wall mount adapter on the
After the
base. Line up the tabs on the wall mount
adapter with the holes on the bottom of
the base. Snap the wall mount adapter
firmly in place.
3.Mount the base on the wall. Position
the base so the mounting studs will fit
into the holes on the bottom of the base.
Position the power cord to extend down
the wall the phone is to be mounted on.
Slide the base down on the mounting
studs until it locks into place.
4.Connect the telephone cord. The
telephone line cord has a snap-in plug
at each end. Insert one of the plugs into
the jack on the bottom of the base. Insert
the other end of the plug into the wall
jack.
FUNCTION KEYS
Keys
OFF KEY
PHONE
CHAN/CLEAR KEY
OFF
Number Keys
*(Tone)
MEM/STORE KEY
CHAN/CLEAR
REDIAL/PAUSE KEY
REDIAL/PAUSE
PROG/MENU
MEM/STORE
Volume Switch
Description
MAKING CALLS
You can make calls by two ways:
1. LIVE DIALING:
* From the Handset, press PHONE key.
SPARE BATT LED
SPARE BATT
CHARGING LED
* The PHONE key will light up to indicate the
IN USE LED
POWER LED line is in use.
* After listening for a dial tone, dial the phone
PAGE KEY
number. The number you dial will also be
displayed on the LCD.
* To end your call, either return the Handset
to the Base Unit cradle, or press the OFF
key on the Handset.
2. PREDIALING:
* Key the telephone number you intend to dial
Description
on your Handset.
AC POWER is present
* Observe that the number you dial is
Phone on
displayed on the LCD. If you dial an
incorrect digit, you may press CLEAR to
delete it and then press again
No battery
* Press PHONE key. The PHONE key will
light up to indicate the line is in use.
* The phone will automatically dial the
telephone number you PRE-dialled.
* To end your call, either return the Handset to
the Base Unit cradle, or press the OFF key
on the Handset.
ANSWERING CALLS
When an incoming call is ringing, the IN USE
LED on the base and PHONE LED on the
handset will flash. To make sure your phone
rings when the handset is away from the base,
please keep the base antenna in the upright
position. Then you may answer calls as
follows:

WALL MOUNTING

5.Connect the power cord. Plug the DC
connector into the DC jack at the rear of
the base unit. Plug the AC power adapter
into an electrical outlet.
6
HANDSET FEATURES
Description
To get dial tone when handset in standby mode. To perform flash operation
when handset is in Talk mode
To hang up a line, or quit a program
For telephone number dialing, programming,etc. (1~9, 0, #)
To change the dialing mode temporarily from pulse to tone during a call.
To change the channel during a call.
To redial the last number dialed. To add a 2-second pause during telephone
number programming.
To enter program mode; -Speed dial memory - Ringer type - Tone/Pulse mode
To save and exit programming mode. To enter memory dialing mode.
To select the handset volume High,Mid or Low.
8
BASIC OPERATIONS
1. From the Handset:
When the handset is in the base, just
pick up the handset.
-- By Live Dialing or
2. Easy Answer:
-- By Pre-Dialing
When the Handset is in Standby mode
and away from the Base Unit, just press
any key except OFF key. This will aid
you in answering calls in a dark
environment.
DISCONNECTING CALLS
Press OFF, or return the Handset to the
Base Unit cradle to end your call.
LINE IN USE
* When the telephone line is engaged by a
parallel telephone, the LCD will show the
following message :
* You may decide to join the telephone
conversation by pressing PHONE, or
make a call later.
PAGE/HANDSET LOCATOR
From the Base Unit, press the PAGE key.
The Handset will ring for approximately 15
seconds. During this time, the Handset
user can:
Press OFF to terminate the ringing or
Ignore the Page from the Base Unit.
Since it will ring for approximately 15
seconds when PAGE is pressed on the
Base Unit, this feature can be helpful in
locating a misplaced Handset.
10
-LINE USED-
