- Page 1 GENEQ F100 User Manual 1 / 26...
- Page 2 This user manual is only for your receiver. If your receiver does not match the case in user manual, the actual situation of the receiver shall prevail. Information in this document is subject to change without notice; GENEQ INC. reserves the right to change or improve its products and to make changes in the content without obligation to notify any person or organization of such changes or improvements.
-
Page 3: Table Of Contents
Contents Product overview __________________________________________________________ 7 Technical Specification __________________________________________________ 10 2.1. GNSS _______________________________________________________________________ 10 2.2. System configuration ______________________________________________________ 11 2.3. Tilt Survey __________________________________________________________________ 11 2.4. Weight and Measurement _________________________________________________ 11 2.5. Environmental _____________________________________________________________ 12 2.6. Electrical ____________________________________________________________________ 12 2.7. Data interface ______________________________________________________________ 12 2.8. - Page 4 3.2. Settings ____________________________________________________________________ 17 3.2.1. Working Mode ___________________________________________________________________ 17 3.2.2. Satellite Settings _________________________________________________________________ 18 3.2.3. Device Configuration ____________________________________________________________ 19 3.2.4. NMEA Message __________________________________________________________________ 20 3.2.5. View Logs ________________________________________________________________________ 20 3.2.6. Configuration Set ________________________________________________________________ 21 3.3. Download __________________________________________________________________ 21 3.3.1. Raw Data ________________________________________________________________________ 21 3.3.2.
- Page 5 Accessories ______________________________________________________________ 28 First, thank you very much for purchasing Geneq F100 geodesic GNSS receiver (hereinafter referred to as F100). F100 is a GNSS receiver with strong performance and constant strength. It takes LINUX system as the development platform, stable and reliable, support secondary development, it can play well in different fields.
-
Page 6: Product Overview
1. Product Overview No receiving satellites； Extinguish: Blink red: Satellites received, but not positioning success； Satellite indicator light Blink green: Positioning success, but not fixed； ❶ Green light on: Fixed solution； Red/Green lights flicker alternately: GNSS motherboard dysfunction; 6 / 26... - Page 7 Green light on: Datalink setup success； Datalink indicator light Blink green: Data transmission； ❷ Blink blue: Blue light flashes according to the set static sampling interval; Extinguish: No Bluetooth connection； Bluetooth indicator light ❸ Blue light on: Bluetooth connection with device; Green light on：Electric quantity: 30%-100%；...
-
Page 8: Technical Specification
2. Technical Specification 2.1. GNSS ● Channels：336 ● Signal tracking Satellite Navigation System Signals L1 C/A, L2E, L2C, L5 GLONASS L1 C/A, L2 C/A, L3 CDMA B1, B2, B3 Galileo E1, E5A, E5B, E5AltBOC, E6 NAVIC SBAS L1 C/A, L5 QZSS L1 C/A, L1 SAIF,L1C, L2C, L5 ●... -
Page 9: System Configuration
● Update rate: up to 50Hz 2.2. System configuration Linux Operation system Internal Storage Bluetooth BT5.0, BLE 802.11b, g, n Hotspot / client mode WIFI Radio RX/TX, Power:5W, Frequency: 403-470MHz Network (EG25-G) Mode Frequency LTE FDD B1/B2/B3/B4/B5/B7/B8/B12/B18/B19/B20/B25/B26/B28 LTE TDD B38/B39/B40/B41 UMTS B1/B2/B4/B5/B6/B8/B19 B2/B3/B5/B8... -
Page 10: Weight And Measurement
2.4. Weight and Measurement 1.55KGS Weight 154mm x 154mm x 76mm Measurement 2.5. Environmental Work temperature -30℃~+65℃ Stock temperature -40℃~+80℃ Humidity 100% Condensing Ingress protection IP67 Withstand 2m along with rod drop onto hardwood Shock &... -
Page 11: User Interface
PC or controllers. The specific operation is as follows. Firstly, make sure that the WIFI mode of F100 is in [hotspot] state. Then open the smartphone /PC/ hand controller and look for the wireless network with the name of SN and connect to the network. -
Page 12: Position
3.1.1. Position 【Position】Here you can view the receiver's position information, including System Mode, Latitude and Longitude, Height, Status, Satellite and so on. 3.1.2. Datalink 【Datalink】Here you can view the receiver's Datalink status. Here you can "connect" or "disconnect" or "restart" the network, as well as “Set Parameters”. "Setting parameters"... -
Page 13: Satellites
3.1.3. Satellites 【Satellites】Here you can view the receiver's satellite list and satellites skyplot, and set the satellite cut-off Angle. 13 / 26... -
Page 14: Information
3.1.4. Information 【Information】Here you can view the receiver's master control board information, Antenna information, GNSS board information, Network information, UHF information. 14 / 26... -
Page 15: Settings
3.2. Settings 【Settings】Here you can set “Working Mode”, “Satellite Settings”, “Device Configuration”, “NMEA Message”, “View logs”, “Configuration set” 3.2.1. Working Mode 【Working Mode】Here you can set “System Mode”, “Current datalink”, “Data type”, “Site ID”, “PDOP Threshold”, “Base Position”, Record Raw Data”, “Network Link”, “APN”, “Network Type”, “Connect mode”, “Caster Address”, “Caster Port”, “Mountpoint”, “Password”, “External serial port baud rate setting”... -
Page 16: Satellite Settings
3.2.2. Satellite Settings 【Satellite Settings】Here you can set “Satellite cutoff Angle”, “GPS, GLONASS, Beidou, GALILEO, SBAS”, ”Receiver dynamic model selection”, and “RTK Timeout” setting. 16 / 26... -
Page 17: Device Configuration
3.2.3. Device Configuration 【Device Configuration】Here you can set “Time zone”, “Direct link Mode”, “Sensors”, 5-pin serial port baud rate”, “Speaker”, “Base Alert”, “Device Debug”, “Power on automatically when connect5-pin cable”, “Network Enable”, “WIFI Hotspot share Network”, “Static File Naming Way” 17 / 26... -
Page 18: Nmea Message
3.2.4. NMEA Message 【NMEA Message】Here you can set “GGA,ZDA,GEDOP,GSA,GSV,GEREF,GST,VTG,GESNR, RMC, GLL, GEVCV and External Port Output NMEA” 3.2.5. View Logs 【View Logs】Here you can view and download “APP Log” and “OS Log”. 18 / 26... -
Page 19: Configuration Set
3.2.6. Configuration Set 【Configuration Set】Here you can upload the configuration file and Save Current Settings. 3.3. Download 【Download】Here you can download the raw data and the backup data. 3.3.1. Raw Data 【Raw Data】Here you can download and delete the original data, and convert according to the required RINEX format and compressed format. -
Page 20: Backup Data
3.3.2. Backup Data 【Backup Data】Here you can download and delete the backup data. 3.4. Management 【Management】Here you can “Upgrade online”, “Device Registration”, “RTX/XTRa License Information checking”, “Security Settings”, “Format Internal Disk”, “Self-Test”, “Restore Factory Settings”, “Reset”. 20 / 26... -
Page 21: Pannel Settings
4. Panel Settings 4.1. Power on or off Short press the power button to start the machine, long press the power button to shut it down. After receiver is started, the default setting will be the working mode setting of the last shutdown, and the setting interface in relevant mode 4.2. -
Page 22: Datalink
4.3. Datalink Here you can make Radio, GPRS, External Settings 【Datalink】 4.3.1. Radio Click "Data link" → click "Radio" to enter the interface of radio setting, including channel and radio protocol setting → Click "Confirm" after setting. GPRS 4.3.2. Click "Data link" → click "GPRS" to enter the GPRS setting interface, which is mainly about “whether automatic APN”... -
Page 23: Differential
4.4. Differential 【Differential】Here you can set the “Differential”. Click "Differential" to enter the interface of Differential format setting. Click "Confirm" after setting. System Settings 4.5. 【Differential】Here you can do backlight time, language Settings. Click "Setting" to set the backlight time and Language. Click "Confirm" after setting. 5. - Page 24 5.2. MEMS Calibration After the instrument reaches the fixed solution and the magnetic calibration be completed, the MEMS calibration can be started. There are two calibration methods: 1. Shake the receiver back and forth; 2. Walk 20 or 30 meters, carrying the instrument. When the MEMS status shows Green “Ready”, the calibration is finished.
- Page 25 5.3. Pole Calibration F100 does not require a dedicated pole. Any pole can be used. It only needs to be calibrated when changing the pole. Each pole should be calibrated only once, as shown in the figure below. Calibration steps: ►...
- Page 26 6. Accessories F100 Accessory Type Model Description Quantity Standard accessories Type-C Port, 15V/3A, With US、 Adapter KSA-45P-45W UK、EU、AU Plug Charging Cable CTMM-1.5 TYPE-C --TYPE-C, 1.5m USB Cable CUTM-1.5 USB--TYPE-C,1.5m UHF Antenna QT400-T TNS-J F:403-473 Tape MTSP4 3m tape Pallet TRB1...
