SW10 Lower Handle Replacement Instructions
1x Phillips Screw Driver
1
Remove the dust tray and tubes from the
main body of the sweeper (Pull tubes out
of the lower handle).
3
Remove the battery. Open the battery
compartment and disconnect the
terminals by pinching the connectors.
5
Once all the screws are removed, lift the
bottom housing off the sweeper.
www.gtechonline.co.uk
2
Remove the visor.
4
Remove 11 screws from the bottom of the
sweeper. (Two are hidden under the rear
wheels; these can be prised out using a
flat–headed screwdriver).
6
This will free the lower handle assembly.
Page 1 of 2
Advertisement
Related Manuals for Gtech SW10
Summary of Contents for Gtech SW10
- Page 1 SW10 Lower Handle Replacement Instructions 1x Phillips Screw Driver Remove the dust tray and tubes from the Remove the visor. main body of the sweeper (Pull tubes out of the lower handle). Remove the battery. Open the battery Remove 11 screws from the bottom of the compartment and disconnect the sweeper.
- Page 2 Simply place the new lower lower handle Ensure that the wires connecting to the assembly (knuckle joint first) in the section battery are fed back through into the at the back of the sweeper. battery compartment before sealing the unit. Replace all 11 screws, making sure all the Turn the sweeper up the correct way, sides are level are sealed –...
