Summary of Contents for Bagotte BG800
- Page 3 4.2 Cleaning Robot 's Filter......20 4.3 Cleaning Robot 's Rolling Brush,Side 3.3 Charge Your Robot........9 3.4 Use Your Robot with the BrushSwivel Wheel........20 Bagotte App..........10 4.4 Clean the Sensors and Charging 3.5 Start/Stop Cleaning........12 Pins...............21 3.6 Cleaning Mode.........13 3.7 Set Time and Scheduled Cleaning..14 3.8 Use the Boundary Strip......16...
- Page 6 English 1.2 Battery and Charging / Information Lithium-ion Battery Important: Lithium-ion batteries and products that contain Lithium-ion are subject to stringent transportation regulations. If you need to ship this product (with the battery included）for service, travel or any other reason,you MUST comply with the following shipping instructions: Remove the Lithium-ion battery from the product.
- Page 10 English 2.6 LED Indication You can see the status of Robot from the LED indicator. Power Status Light Status Charging Breathing purple Standby / Cleaning / Fully charged Solid blue Low power and returning to Charging Base Solid purple • Robot is o .
- Page 12 English Connect the round connector of the adapter into the power socket on the Charging Base and the other end into a wall outlet. - Install the Charging Base in a location that Robot can easily access. It is recommended to place the Charging Base against a wall, and on a hard-level surface rather than on rugs or carpets.
- Page 20 Once you have found the “Smart Life ” skill, tap Enable. Login with your Bagotte a ccount so that Alexa can control your robot Say simple commands to Alexa. Alexa,turn on “robot name”. Alexa,turn off “robot name”. - 17 -...
- Page 21 Google action for Robot. Follow the instructions in the Google Home app to authorize the Google Assistant with your Bagotte App account. To control Robot with your voice, say simple commands to Google Assistant. Ok Google, turn on “robot name”.
- Page 22 To keep robot running at peak performance, perform the following care procedures.If you notice robot picking up less debris from your floor, then empty the bin, clean the filter and rolling brush. Recommended cleaning / replacement frequency : BG800 Cleaning Replacement Frequency...
- Page 23 English 4.2 Cleaning Robot 's Filter Remove filter by grasping the white tab. Shake o debris by tapping the filter against your trash container. 4.3 Cleaning Robot 's Rolling Brush,Side Brush, Swivel Wheel Take out the rolling brush,clean the vacuuming aisle by a cloth. Clean the rolling brush.
- Page 24 English Pull out the swivel wheel, then clean the Swivel Wheel with the cleaning tool. 4.4 Clean the Sensors and Charging Pins To maintain the best performance, clean the drop sensors and charging pins regularly. • Dust o the drop sensors and charging contact pins using a cloth or cleaning brush. - 21 -...
- Page 25 English 5 Troubleshooting 5.1 Error Tones When robot is in trouble, it will emit a series of short or long beeps and the red indicator on robot will be solid or flashing. Flashing red indicator light Error Tone Cause Solution Two beeps Robot’s bumper is stuck.
- Page 26 Air-dry the filters completely before use. • Check if the indicator on the Charging Base lights up. If not, contact the bagotte service center to repair or replace the Charging Base. • Dust o the charging contact pin with a dry cloth.
- Page 27 - A future software release will support access to channels above 11 for users outside North America. Until then, use channels 1-11. If you cannot control robot with your smartphone, try the solutions below to solve the problem. If the problem persists, contact the Bagotte service center for help. - 25 -...
- Page 28 Reset Wi-Fi connection if necessary. Refer to the “Use Your Robot with the Bagotte App > Reset Wi-Ficonnection”section in this manual. Slowly flashing Wi-Fi connection is reset Set up Wi-Fi connection with Robot. Refer to the...
