GENERAL SAFETY INFORMATION

• To reduce the risk of death, personal injury or property damage from fire,
electric shock, falling parts, cuts/abrasions and other hazards, please read
all warnings and instruc�ons included with and on the fixture box and all
fixture labels.
• Before installing, servicing, or performing rou�ne maintenance upon this
equipment, please follow these general precau�ons.
• Commercial installa�on, service and maintenance of luminaires should be
performed by a qualified electrician.
• DO NOT INSTALL DAMAGED PRODUCT!
• This fixture is intended to be connected to a properly installed and
grounded UL listed junc�on box.
• Make sure that the supply voltage is the same as the luminaire voltage.
• DO NOT install where the marked opera�ng temperatures exceed the
igni�on temperatures of the hazardous atmosphere.
• DO NOT operate in ambient temperatures above those indicated on the luminaire nameplate.
• All gasket seals must be clean and undamaged.
WARNING
RISK OF ELECTRICAL SHOCK
• Turn off electrical power at fuse or circuit breaker box before wiring fixture to the power supply.
• Turn off the power when you perform any maintenance.
• Verify that supply voltage is correct by comparing it with the luminaire label informa�on.
• Make all electrical and grounded connec�ons in accordance with the Na�onal Electrical Code and
any applicable local code requirements.
• All wiring connec�ons should be capped with UL approved wire connectors.
• Luminaire must be supplied by a wiring system with an equipment grounding conductor.
CAUTION
RISK OF INJURY
• Wear gloves and safety glasses at all �mes when removing luminaire
from carton, installing, servicing or performing maintenance.
• Avoid direct eye exposure to the light source while it is on.
• Account for small parts and destroy packing material, as these may
be hazardous to children.
CAUTION
RISK OF FIRE
• Keep combus�ble and other materials that can burn away from
luminaire and lamp/lens.
• MIN 90ºC SUPPLY CONDUCTORS.
07/29/20
ETG-HLB
HazLoc Low Bay User Manual
LMAN0070-01-EN
Hazardous Location Series
Image is for iillustra�on purposes only.
Your model may vary.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hazardous Location Series and is the answer not in the manual?

Questions and answers

Related Manuals for HORNER Hazardous Location Series

Summary of Contents for HORNER Hazardous Location Series

  • Page 1 LMAN0070-01-EN Hazardous Location Series ETG-HLB HazLoc Low Bay User Manual GENERAL SAFETY INFORMATION • To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts/abrasions and other hazards, please read all warnings and instruc�ons included with and on the fixture box and all fixture labels.
  • Page 2 LMAN0070-01-EN Hazardous Location Series GENERAL WIRING DIAGRAM • CAUTION: Turn off electrical power at fuse BLACK (LINE) or circuit breaker box before wiring fixture to the power supply. GREEN (GROUND) LED Driver Terminal AC INPUT Block WHITE (NEUTRAL) Connec�ng panels to AC source supply: All units must be individually connected to the AC supply.
  • Page 3 LMAN0070-01-EN Hazardous Location Series Installa�on: Pendant Step 1. Fix the Tank cover on the NPT 3/4” threaded pipe then �ghten M4 fastening screws Step 1 Step 2. Connect electrical part Step 3. Use three M5 socket head cap screws to fix the luminaire with torque value 5 N-m.
  • Page 4 LMAN0070-01-EN Hazardous Location Series Ceiling Step 1. Use four M8 expansion bolts to fix the Step 1 bracket to the ceiling Step 2. Use the six M4 hexagon socket screws with Step 2 torque value 3 N-m to fix the driver cavity cover to the bracket Step 3.
  • Page 5 LMAN0070-01-EN Hazardous Location Series Wiring Installa�on In the FIGURE A, the NPT 3/4” joint is sealed with a pipe sealant or p�e tape Figure A This device complies with part 15 of the FCC Rules. Opera�on is subject to the following two condi�ons: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired opera�on.
  • Page 6 LMAN0070-01-EN Hazardous Location Series SERVICING • To avoid personal injury, disconnect power to the light and allow the unit to cool down before performing maintenance. • Perform visual, electrical and mechanical inspec�ons on a regular biasis. The environment and frequency of use should determine this. However, it is recommended that checks should be made at least once a year.
