- Page 1 HD Wi-Fi IP Camera User's Manual [V1.01]...
-
Page 2: Table Of Contents
Table of contents 1.Package Content..........................3 2.Product Layout ..........................3 3.Getting Started ..........................4 3.1 Download Yes iCam APP ......................4 3.2. Power on the camera......................4 3.3 First-time Setup ........................5 3.4 Add camera ..........................7 3.5 Reset the camera to factory default ..................8 Operation Mode ........................9 4.1 Viewing Live Video ........................9 4.2 Camera Setting........................10... - Page 3 Watch the things that matter to you anytime and anywhere It can connect with your Smartphone or tablet via wireless technology, and monitor everything that matters to you on your Smartphone or tablet anywhere and anytime. Before you start you need： ： ： ： iPhone, iPad, IP Camera Wi-Fi Router...
-
Page 4: Package Content
1.Package Content Item Q'ty Item Q'ty Item Q'ty IP Camera 1pcs 6V Adapter 1pcs User's Manual 1pcs 1pcs 2. Product Layout Light sensor Microphone Camera lens Infrared LEDs Speaker Reset button Power/ status LED Antenna Temperature sensor Power adapter socket Micro SD Card slot micro... -
Page 5: Getting Started
3.Getting Started 3.1Download “Yes iCAM”App Key in the keyword “Smart iCAM” and download the app from Apple App Store (iPhone/iPad) or Google Play Store (Android). 3.2. Power on the camera 1. Plug one end of the provided power adapter into a wall outlet and the other end into the back of the camera. -
Page 6: First-Time Setup
3.3 First-time Setup 3.3.1 Connect your Smartphone or tablet to the camera 1. Turn on the Wi-Fi of your Smartphone or tablet 2. Click the reset button for about 5 second until you hear three peeping sound, then wait for 25~30 seconds 3. - Page 7 Note 1: Wi-Fi SSID is the wireless network name 2:If the camera cannot find the Wi-Fi network you wish to connect to, please make sure the camera and the Wi-Fi router are within range of each other. 。 。 。 。 3: If you type in the wrong SSID password the camera will beep three times Please close the App and followe step3.3 to setup camera again...
-
Page 8: Add Camera
3. Touch the image display area of the screen and move fingers apart for digital zoom function. 3.4 Add camera to other Smartphone or tablets 3.4.1Add camera in Local Area Network(LAN) 1. Turn on the Wi-Fi of your smartphone or tablet 2. -
Page 9: Reset The Camera To Factory Default
3.4.2 Add camera through remote setup 1. Turn on the Wi-Fi of your smartphone or tablet 2. Launch the Yes iCAM app on your smartphone or tablet, Tap the “Add New Camera”, and then tap the“Add Remote Camera” icon to enter “Add a Remote Camera” screen, Enter Camera UID, Password (The default password is “admin”）... -
Page 10: Operation Mode
Note: 1:If you do not hear a beeping sound, please re-press the reset button. 2: If you want to change the connection between the camera and Wi-Fi router or if you forget the camera password, you need to reset the camera to factory default. Please refer to 3.3 - First time setup of this user manual to set up the camera again. -
Page 11: Camera Setting
Tap the icon to save a snapshot of the camera on you smartphone of tablet 8.Audio ON/OFF Tapping the icon can turn on/off sound When the audio icon is off ,you can speak through the camera until from your smartphone or tablet. - Page 12 Restart Yes iCam app enter camera internet setting tap the Wi-Fi SSID that you want to connect ： ： ： ： Note After replacing WiFi, smart phone or tablet PC and the camera needs to be carried out in the same LAN other settings. 6.
- Page 13 Tap the icon to enable HD 720p recording, tap it again to disable recording. Note: 1: Recording is only possible when a micro SD card is inserted into camera. 2: The system supports SD cards with a maximum capacity of 32GB. 3: 1GB memory card is able to record around 1 hour of video.
- Page 14 Note :Some functions cannot be set when your mobile and camera are not the same network (SSID). - Change Name/Password - Motion Detection - Record - VOX Detection - Video Setting...
- Page 15 5.Troubleshooting Cannot connect the camera to your smartphone/tablet through Wi-Fi router or 3G/4G mobile network - Make sure the power plug is pushed all the way in. - Make sure the camera is turned on and power/status LED glows green. - Make sure the camera and the Wi-Fi router are within range of each other.
- Page 16 Specifications Camera Frequency 2.4 GHz ISM band Antenna Dipole antenna Modulation DBPSK, DQPSK, CCK and OFDM Image Sensor 1/6" Color CMOS Lens f 3.0mm, F 2.4 IR LED 8 pcs Video compression H.264 Audio Two-way audio talk SD Card Recording Support Micro SDHC Card, class 6 or above, up to 32GB Pan and Tilt...
- Page 17 FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could ...
