- Page 1 Fiber Optic Prism Switch ’ ANUAL...
-
Page 2: Limitation Of Warranty
Warranty Newport Corporation warrants this product to be free from defects in material and workmanship for a period of one year from the date of shipment. If found to be defective during the warranty period, the product will either be repaired or replaced at Newport's option. - Page 3 This manual has been provided for information only and product specifications are subject to change without notice. Any change will be reflected in future printings. © 1999 Newport Corporation 1791 Deere Ave. Irvine, CA 92606 (949) 863-3144 P/N 28989-01, Rev. A (IN-06999) (9/99)
-
Page 4: Table Of Contents
Table of Contents Warranty ...............ii Limitation of Warranty.........ii Section 1 - Introduction........1-1 Scope ............1-1 Safety Considerations.........1-1 Convention and Symbols......1-2 1.3.1 Safety and General Symbols/ Definitions ........1-2 1.3.2 Terminology .........1-2 Product Overview........1-4 Section 2 – Switch Control.........2-1 Non-Latching Two-Pin Control ....2-2 Section 3 - Specifications........3-1 Housing Dimensions ........3-2 Section 4 –... - Page 5 List of Figures Figure 1.1 – Fiber Optic Prism Switch ..............1-4 Figure 2.1 – Two-Pin Control Electrical Schematic..........2-2 Figure 3.1 – Housing Dimensions for 1x2 Prism Switch ........3-2 Figure 3.2 – Housing Dimensions for 2x2 Prism Switch ........3-3 Figure 4.1 – Fiber Optic Component ..............4-2 List of Tables Table 2.1 –...
- Page 6 Preface...
-
Page 7: Section 1 - Introduction
Section 1 Introduction Scope This manual provides descriptions and operating information for the Fiber Optic Prism Switch. Section 1, Introduction includes safety considerations, conventions and definitions, and a product overview. Section 2, Switch Control includes specific information, non-latching two-pin control description and schematic, and related tables. -
Page 8: Convention And Symbols
To protect the product from damage and avoid hazardous situations, follow these recommendations: • Do not make modifications to the product. • Return the product to Newport Corporation for service and repair. • Keep liquids away from the product. •... - Page 9 Directivity The ratio of the power returned to any other input port to the launched power, expressed in Excess Loss The ratio of the total power at all output ports to the launched power, expressed in dB. Isolation The ratio of the power at an output port in the transmitted wavelength band to that in the extinguished wavelength band.
-
Page 10: Product Overview
Product Overview Newport's 1x2 and 2x2 Prism Switch provides channel selection from one or two input fibers to two output fibers, using a moving prism between fixed collimators. Newport's 1x2 and 2x2 switches are actuated electrically and require +5 VDC to switch position. -
Page 11: Section 2 - Switch Control
Section 2 Switch Control The four-pin electrical interface is used to control and monitor switch position. The electrical connector is Molex P/N 22-23-2041, and mates with Molex P/N 22- 01-3047 or equivalent. Pin 4 is the position sensor output. The output alternates between normal open contact and normal close contact (low or high signal) depending on the switch position. -
Page 12: Non-Latching Two-Pin Control
Input 1 Output 1 Input 1 Output 1 Input 2 Output 2 Input 2 Output 2 Switch Position Switch Position Actuation Style Control Sensor Control Sensor Pin 1 Pin 2 Pin 3 Pin 4 Pin 1 Pin 2 Pin 3 Pin 4 Non-Latching High... -
Page 13: Table 3.1: Optical Specifications
Section 3 Specifications Parameter Minimum Typical Maximum Units Wavelength range 1290 1570 Insertion loss Back-reflection (single-mode) Back-reflection (multimode) Switching time Cross-talk Durability Megacycles ± 0.01 Repeatability ** PDL *** 0.05 All specifications referenced without connectors Repeatability for 100 cycles at constant temperature Single-mode only. -
Page 14: Figure 3.1: Housing Dimensions For 1X2 Prism Switch
Parameter Minimum Typical Maximum Units Operating temperature °C Storage temperature °C Humidity 60°C / 90% 60°C / 90% 60°C / 90% RH / 14 RH / 14 RH / 14 days days days Table 3.3: Environmental Specifications Housing Dimensions The following illustrations, Figure 3.1 and Figure 3.2 show the Housing Dimensions for 1x2 and 2x2 Prism Switch. -
Page 15: Figure 3.2: Housing Dimensions For 2X2 Prism Switch
74.5 67.0 11.4 11.0 26.0 32.0 Input 1 Output 1 20.0 Input 2 Output 2 40.0 ÿ 3.2 Through 61.0 Mounting Hole 2 Places 2.54 Pin 1 2 Places 16.0 Aux. Blind Mounting Hole 10.1 M3X0.5 3.00 DP 2 Places 25.6 Units: mm Figure 3.2: Housing Dimensions for 2x2 Prism Switch... -
Page 16: Section 3 - Specifications
Section 3 - Specifications... -
Page 17: Section 4 - Handling Fiber Optic Components And Cables
Section 4 Handling Fiberoptic Components and Cables Handling Fiber Optic Cables The user's switch may come with fiber pigtail outputs. Treat cables with care to avoid cable damage and minimize optical loss. The minimum bend radius for most optical cables is 35mm. Never bend an optical cable more sharply than this specification. -
Page 18: Storing Optical Connectors
In order to obtain the most stable, repeatable • optical performance, immobilize optical cables using wide pieces of tape or some form of mechanical cushion after the optical cables have been connected. Figure 4.1: Fiber Optic Component Storing Optical Connectors All switches are shipped with dust caps in place covering all optical connectors. -
Page 19: Mating Optical Connectors
To clean with alcohol and a swab, dab the tip of a cotton swab in alcohol and then shake off any excess alcohol. The tip should be moist, not dripping wet. Stroke the swab tip gently across the surface of the connector and around the connector ferrule. - Page 20 Optical power trending (slowly increasing or decreasing) is caused by the slow evaporation of alcohol trapped in the connection. Continue to monitor optical power until it stabilizes. If the loss is unacceptable, re-clean the connector and start again. Section 4 – Handling Fiber Optic Components and Cables...
-
Page 21: Section 5 - Factory Service
Fiber Optic Prism Switch product. The user should not attempt any maintenance or service of the product. Any problem that cannot be resolved should be referred to Newport Corporation. Technical Customer Support contact information is listed in Table 5.1. - Page 22 Service Form Newport Corporation U.S.A. Office: 949/863-3144 FAX: 949/253-1800 Name _______________________ RETURN AUTHORIZATION # _____________ (Please obtain prior to return of item) Company __________________________________ Address ______________________________________________ Date ___________ Country _____________________________ Phone Number ____________________ P.O. Number _________________________ FAX Number _____________________ Item(s) Being Returned:...
- Page 23 Worldwide Headquarters 1791 Deere Avenue Irvine, CA 92606 (In U.S.): 800-222-6440 Tel: 949-863-3144 Fax: 949-253-1680 Internet: sales@newport.com Visit Newport Online at: www.newport.com Newport Corporation, Irvine, California, has been P/N 28989-01, Rev. A certified compliant with IN-06999 (07/00) ISO 9001 by British Standards Institution.
