- Page 1 HOSCH PRE- SCRAPERS TYPE HD-PU-L Installation and Operation Manual...
- Page 2 4. Periodic maintenance according to these instructions Intended use The HOSCH pre-scraper Type HD-PU-L is installed at the discharge pulley of the conveyor belt system, reducing the material layer sticking to the belt. Consequently, the following main scraper can operate under more favourable conditions, resulting in optimal overall cleaning results.
- Page 3 Do not attempt to make any modifications or alterations to the device regarding the configuration, installation, operation and maintenance without written approval from HOSCH. Unauthorised modifi- cations or alterations to the device could lead to serious damage to property and personnel.
- Page 4 Main items – Belt width 1,200 - 2,400 mm Cleaning block Assembly carrier midsection Assembly carrier end section Mounting with tensioning unit The contents of this document may be subject to technical modifications Page 4 of 14 Installation and Operation Manual Type HD-PU-L...
-
Page 5: List Of Tools
DESCRIPTION (Continued) Design The HOSCH pre-scraper Type HD-PU-L is known as a head-pulley scraper. The characteristics of the scraper are the single-row PU cleaning blocks. For belt widths up to 1,050mm, the assembly carrier is of a one-piece design and is fitted with one single tensioning unit. For belt widths of more than 1,050mm, the scraper is equipped with 2 tensioning units and the assembly carrier is divided into 3 parts. -
Page 6: Determine The Installation Position
“PC”. 2. The mountings should preferably be installed at solid unbendable conveyor frame parts, e.g. beams. ∅14 The contents of this document may be subject to technical modifications Page 6 of 14 Installation and Operation Manual Type HD-PU-L... - Page 7 Install the mounting on one side. For belt widths up to 1,050mm, install only one mounting in the first step. The contents of this document may be subject to technical modifications Page 7 of 14 Installation and Operation Manual Type HD-PU-L...
- Page 8 5. Install the cleaning blocks Fix the cleaning blocks (1) to the assembly carrier (3) with the set of bolts (2). The contents of this document may be subject to technical modifications Page 8 of 14 Installation and Operation Manual Type HD-PU-L...
- Page 9 4a and 6a. The contents of this document may be subject to technical modifications Page 9 of 14 Installation and Operation Manual Type HD-PU-L...
- Page 10 2. Turn the tension lock (1) down. 3. The tensioning unit is now active and presses the clean- ing blocks against the belt. The contents of this document may be subject to technical modifications Page 10 of 14 Installation and Operation Manual Type HD-PU-L...
-
Page 11: Trial Run
Make sure that there are no persons in the dangerous areas of the conveyor. Pay attention to the rules on how to restart the conveyor belt safely. The contents of this document may be subject to technical modifications Page 11 of 14 Installation and Operation Manual Type HD-PU-L... -
Page 12: Maintenance And Service
Maintenance Under normal operating conditions carry out an inspection every 8 to 12 weeks. If necessary carry out any maintenance work required. Please contact HOSCH for all questions about maintenance intervals and required maintenance steps. Maintenance steps 1. Clean all scraper components. -
Page 13: Technical Alterations
Upon request, the HOSCH service department can coordinate the required inspection and service work. HOSCH service staff are available world-wide to carry out the work. In addition, HOSCH offer customer training seminars on the selection, installation, inspection and service of its conveyor belt cleaning and tracking systems. - Page 14 No part of this publication may be reproduced, transmitted, transcribed, stored in any retrieval system or translated into any human or computer language by any means or in any form, without the prior written permission of HOSCH Fördertechnik GmbH. Contravention of the owner's copyright may also reduce the ability of HOSCH Fördertechnik GmbH to provide effective support for its equipment.
