- Page 1 MegaRAID® LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide Preliminary, Revision D September 2010...
-
Page 2: Revision History
LSI Corporation to make a commercial release of the product. LSI Corporation reserves the right to make changes to the product(s) or information disclosed herein at any time without notice. LSI Corporation does not assume any responsibility or liability arising out of the application or use of any product or service described herein, except as expressly agreed to in writing by LSI Corporation;... - Page 3 Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit The MegaRAID LSIiBBU07 is an intelligent battery backup unit (iBBU) that protects the integrity of the cached data on a MegaRAID RAID controller for up to 72 hours in case of a complete AC power failure or a brief power outage.
- Page 4 Backup Units for MegaRAID SAS RAID Controllers User Guide or the MegaRAID 6Gb/s SAS RAID Controllers User Guide. LSI provides a family of MegaRAID iBBUs for use with its high-performance MegaRAID RAID controllers. The LSI MegaRAID iBBUs provide an inexpensive alternative to using an uninterruptible power supply (UPS) and a second level of fault tolerance when used with a UPS.
- Page 5 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide Installing the LSIiBBU07 Unit Directly on a MegaRAID SAS RAID Controller NOTE: For technical specifications for this battery, refer to the Battery Backup Units for MegaRAID SAS RAID Controllers User Guide.
- Page 6 Installing the LSIiBBU07 Unit Directly on a MegaRAID SAS RAID Controller MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide 4. Place the RAID controller with the front side facing upward on a flat, clean, static-free surface. 5. Hold the LSIiBBU07 daughtercard so that the battery side is facing upward and the...
- Page 7 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide Connecting the LSIiBBU07 Unit Remotely to the MegaRAID SAS RAID Controller Bracket Screw Press Here LSIiBBU07 (Top View) Press Here 85021-04 Edge of Motherboard Edge of Motherboard Figure 3: Reinstalling the MegaRAID SAS Controller 4.
- Page 8 Connecting the Remote LSIiBBU07 Unit to the BBU Connector on the RAID Controller MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide 1. Remove the controller from the computer. 2. Mount the LSIiBBU07 unit to the chassis. 3. Connect the controller to the remote LSIiBBU07 unit using the 12-in., 20-pin cable and the BBU connector on the RAID controller (the LSIiBBU07 unit must be mounted inside the chassis within 10 inches of the controller).
- Page 9 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide Connecting the Remote LSIiBBU07 Unit to the BBU Connector on the RAID Controller 85021-15 Figure 4: Connecting the LSIiBBU07 Unit Remotely to the SAS 8880EM2 RAID Controller Follow these steps to reinstall the RAID controller on a motherboard.
- Page 10 Connecting the Remote LSIiBBU07 to the Daughtercard on the RAID Controller MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide Bracket Screw Press Here Press Here 85021-16 Edge of Motherboard Edge of Motherboard Figure 5: Installing the MegaRAID SAS Controller 4.
- Page 11 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide Connecting the Remote LSIiBBU07 to the Daughtercard on the RAID Controller NOTE: Because server and workstation chassis vary from vendor to vendor, there is no standard mounting option that is compatible with the various system configurations.
- Page 12 Connecting the Remote LSIiBBU07 to the Daughtercard on the RAID Controller MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide Figure 6: Connecting the Daughtercard to the RAID Controller Follow these steps to connect the cable between the daughtercard on the controller...
- Page 13 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide Connecting the Remote LSIiBBU07 to the Daughtercard on the RAID Controller 85021-13 Figure 7: Connecting the LSIiBBU07 Unit Remotely to the MegaRAID SAS Controller Follow these steps to install the controller in the computer.
- Page 14 NOTE: Record your controller serial number in a safe location in case you need to contact LSI about your RAID controller. Click the following link to access the LSI technical support web page for storage and board support: http://www.lsi.com/support/storage/tech_support/index.html From this web page, you can send an email or call technical support, or submit a new support request and view its status.
- Page 15 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide Technical Support Phone Support: http://www.lsi.com/support/storage/phone_tech_support/index.html NOTE: The international toll-free number does not require country-specific access codes. LSI Corporation Confidential September 2010 Page 15...
- Page 16 34231- 00D...
