- Page 1 MegaRAID® LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 34231-01, Rev. A...
-
Page 2: Revision History
LSI Corporation reserves the right to make changes to the product(s) or information disclosed herein at any time without notice. LSI Corporation does not assume any responsibility or liability arising out of the application or use of any product or service described herein, except as expressly agreed to in writing by LSI Corporation; nor does the purchase, lease, or use of a product or service from LSI Corporation convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Corporation or of third parties. -
Page 3: Product Overview
MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide Thank you for purchasing the LSI® MegaRAID® LSIiBBU07 product. Before you install your RAID controller, take a few minutes to read this quick installation guide. This guide explains how to install the LSIiBBU07 unit directly on your RAID controller or connect the LSIiBBU07 unit remotely to the RAID controller. - Page 4 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Front View and Rear View of the LSIiBBU07 Unit MegaRAID SAS 9280-8e — MegaRAID SAS 9280DE-8e — Mode 4: Connect a 12-in. cable between a LSIiBBU07 unit on a remote mount board and a board-to-board cable ...
- Page 5 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Installing a LSIiBBU07 Unit Directly on a MegaRAID SAS RAID Controller J2 Remote Connector Battery Pack Harness NOTE For technical specifications for this battery backup unit, refer to the Cache Backup Products for SAS+SATA RAID Controllers User Guide.
- Page 6 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Installing a LSIiBBU07 Unit Directly on a MegaRAID SAS RAID Controller Installing the LSIiBBU07 Unit on the RAID Controller Follow these steps to install the LSIiBBU07 unit on the front of the SAS 8880EM2 RAID controller.
- Page 7 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Installing a LSIiBBU07 Unit Directly on a MegaRAID SAS RAID Controller Reinstalling the RAID Controller Follow these steps to reinstall the RAID controller on the motherboard.
- Page 8 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting a Remote LSIiBBU07 Unit to a MegaRAID SAS RAID Controller Connecting a Remote LSIiBBU07 Unit to a MegaRAID SAS RAID Controller The following sections describe the three methods you can use to connect a LSIiBBU07 unit remotely to your MegaRAID SAS RAID controller using the 12-in., 20-pin cable (sold separately in a Remote Battery Kit).
- Page 9 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting a Remote LSIiBBU07 Unit to the BBU Connector on the RAID Controller Removing the RAID Controller from the Computer Follow these steps to remove the RAID controller from the computer.
-
Page 10: Reinstalling The Raid Controller On The Motherboard
MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting a Remote LSIiBBU07 Unit to the BBU Connector on the RAID Controller Reinstalling the RAID Controller on the Motherboard Follow these steps to reinstall the RAID controller on a motherboard. - Page 11 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting a Remote LSIiBBU07 Unit on the System Chassis to a Board-to-Board Cable Adapter Card on a RAID Controller Connecting a Remote LSIiBBU07 Unit on the System Chassis to a Board-to-Board Cable...
- Page 12 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting a Remote LSIiBBU07 Unit on the System Chassis to a Board-to-Board Cable Adapter Card on a RAID Controller Installing the Board-to-Board Cable Adapter Card on the RAID Controller Follow these steps to install the board-to-board cable adapter card on the controller, as shown in the following figure.
- Page 13 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting a Remote LSIiBBU07 Unit on the System Chassis to a Board-to-Board Cable Adapter Card on a RAID Controller Connecting the Cable between the Board-to-Board Cable Adapter Card on the RAID Controller and the Remote LSIiBBU07 Unit on the System Chassis Follow these steps to connect the cable between the adapter card on the RAID controller and the LSIiBBU07 unit.
- Page 14 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting a Remote LSIiBBU07 Unit on the System Chassis to a Board-to-Board Cable Adapter Card on a RAID Controller Reinstalling the RAID Controller Follow these steps to install the RAID controller in the computer.
- Page 15 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting an LSIiBBU07 Unit from a Remote Mount Board to a Board-to-Board Adapter Card on a RAID Controller Connecting an LSIiBBU07 Unit from a Remote Mount Board to a Board-to-Board...
- Page 16 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting an LSIiBBU07 Unit from a Remote Mount Board to a Board-to-Board Adapter Card on a RAID Controller Installing the Board-to-Board Cable Adapter Card on the RAID Controller Follow these steps to install the board-to-board cable adapter card on the controller, as shown in the following figure.
- Page 17 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting an LSIiBBU07 Unit from a Remote Mount Board to a Board-to-Board Adapter Card on a RAID Controller Connecting the LSIiBBU07 Unit on the Remote Mount Board to the Board-to Board Cable Adapter Card...
- Page 18 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting an LSIiBBU07 Unit from a Remote Mount Board to a Board-to-Board Adapter Card on a RAID Controller Reinstalling the RAID Controller Follow these steps to reinstall the RAID controller in the computer.
- Page 19 MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide MegaRAID LSIiBBU07 Intelligent Battery Backup Unit Quick Installation Guide October 2011 Connecting an LSIiBBU07 Unit from a Remote Mount Board to a Board-to-Board Adapter Card on a RAID Controller Installing the Remote Mount Board Follow these steps to install the remote mount board in the computer.
-
Page 20: Technical Support
Technical Support For assistance installing your LSIiBBU07 unit, contact an LSI Technical Support representative. NOTE Record your controller serial number in a safe location in case you need to contact LSI about your RAID controller. Click the following link to access the LSI technical support web page for storage and board support: http://www.lsi.com/about/contact/pages/support.aspx... - Page 22 34231-01A...
