- Page 1 691 Keypad INSTALLATION AND PROGRAMMING GUIDE ABC( DEF) GHI! JKL? MNO/ PQR& STU$ VWX, YZ_’ -.*#...
-
Page 3: Table Of Contents
TABLE OF CONTENTS About the 691 Keypad ....... 1 Installer Options Menu.......7 2-Button Panic Keys ..........1 Accessing Installer Options ......7 Internal Speaker ............ 1 Keypad Options ........... 7 External Sounder ..........1 Keypad Diagnostics ..........9 Exit the Installer Options ........9 Install the Keypad ........2... - Page 4 Keypad Base LCD Display Select Keys Number Keys Keypad Cover Tamper-Proof Screw Figure 1: 691 Keypad...
-
Page 5: About The 691 Keypad
ABOUT THE 691 KEYPAD The Model 691 is a weatherproof outdoor keypad mounted on an aluminum black powder coated box. 2-Button Panic Keys External Sounder Enable the Panic key function in the keypad The keypad provides a switched ground for an user menu. -
Page 6: Install The Keypad
Place the front cover onto the base and line up the screw holes to the base. Secure the cover to the base with the included six tamper-proof screws using the tamper bit. See Figure 3. 691 Keypad Installation and Programming Guide Digital Monitoring Products, Inc. - Page 7 Yellow – Send Data Red – Keypad Power Figure 2: Wiring Harness Mounting Hole Screw Holes for Front Cover Contrast Setting Gasket Keypad Harness Connection CONTRAST Figure 3: Inside Base View Figure 4: Keypad PCB Digital Monitoring Products, Inc. 691 Keypad Installation and Programming Guide...
-
Page 8: User Options
Set the keypad internal speaker tone. At the SET TONE display, ▐▐▐▐▐▐▐ < > use the left Select key to lower the tone and the right Select key to raise the tone. 691 Keypad Installation and Programming Guide Digital Monitoring Products, Inc. - Page 9 The LCD displays the keypad model number and firmware version 691 V100 041811 and date. The user cannot change this information. Keypad Address KEYPAD ADDRESS The LCD displays the current keypad address. The user cannot change the keypad address. Digital Monitoring Products, Inc. 691 Keypad Installation and Programming Guide...
-
Page 10: Type In The Keypad
See Figure 6. ABC( DEF) GHI! JKL? MNO/ PQR& STU$ VWX, YZ_’ -.*# First Letter Third Letter Special Character Second Letter Figure 5: Alpha Characters Figure 6: Non-Alpha Characters 691 Keypad Installation and Programming Guide Digital Monitoring Products, Inc. -
Page 11: Installer Options Menu
01. To change the current address, press any Select key and enter the new address. It is not necessary to enter a leading zero for addresses 01 to 09. Digital Monitoring Products, Inc. 691 Keypad Installation and Programming Guide... - Page 12 To enable or disable a Panic, press the Select key under the appropriate display: PN (Panic), EM (Emergency), and FI (Fire). Once the panic is enabled, an asterisk displays next to the description. 691 Keypad Installation and Programming Guide Digital Monitoring Products, Inc.
-
Page 13: Keypad Diagnostics
Exit the Installer Options When done, press the CMD key once to return to the Installer Options screen. Press the Select key under STOP to exit the Installer Options function. Digital Monitoring Products, Inc. 691 Keypad Installation and Programming Guide... -
Page 14: Additional Power Supply
Connect all keypad power (+12 VDC) wires to the power supply positive terminal. Do not connect the power supply positive terminal to any panel terminal. Refer to the 505-12 Power Supply Installation Guide (LT-0453). 691 Keypad Installation and Programming Guide Digital Monitoring Products, Inc. -
Page 15: Keypad Bus Wiring Specifications
When voltage is too low, the devices cannot operate properly. For additional information refer to the panel’s Installation Guide or the 710 Installation Sheet (LT-0310). Also see the LX-Bus/Keypad Bus Wiring Application Note (LT-2031). Digital Monitoring Products, Inc. 691 Keypad Installation and Programming Guide... -
Page 16: Product Specifications
PRODUCT SPECIFICATIONS Operating Voltage 12 VDC Dimensions 5.76 W x 8.76 H x 2.75 D in 14.63 W x 22.25 H x 6.99 D cm 691 Keypad Installation and Programming Guide Digital Monitoring Products, Inc. - Page 17 • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Digital Monitoring Products, Inc. 691 Keypad Installation and Programming Guide...
- Page 18 Information furnished is believed to be accurate and reliable. This information is subject to change without notice. 691 Keypad Installation and Programming Guide Digital Monitoring Products, Inc.
- Page 20 LT-1170 20233 © 2020 Digital Monitoring Products, Inc.
