5. The image shows how the main support tube
should look like when connected and assembled.
6. Take the 2 handle sections and place the bottom
section in position on the centre support column,
line the holes up and fix in place using the stainless
steel screws M6x10.
7. Place the plastic cover over the screw section on
the back of the vibration plate.
8. The image shows the back section completely
assembled.
5
