STOCKHOLM 3 + 2 DRAWER CHEST
DO NOT
USE
PLEASE READ BEFORE YOU CONTINUE FURTHER
THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF
SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND
PERIODIC MAINTENANCE AND CLEANING.
ASSEMBLE ON A SOFT CLEAN SURFACE.
DO NOT USE ANY TOOLS OTHER THAN THOSE SHOWN.
ANY SPANNERS OR ALLEN KEYS REQUIRED ARE INCLUDED WITH THE
FITTINGS KIT.
DO NOT FOR ANY REASON USE A POWER TOOL TO ASSEMBLE THIS
PRODUCT. ITS USE WILL INVALIDATE ANY CLAIM YOU MAY HAVE AND
COULD MAKE THIS PRODUCT UNSAFE.
DEPENDING ON THE AMOUNT OF USE THIS PRODUCT RECEIVES IT MAY BE
NECESSARY TO TIGHTEN UP THE FIXINGS FROM TIME TO TIME. THIS IS
COMPLETELY NORMAL FOR ANY FLAT PACK FURNITURE.
DO NOT OVERTIGHTEN FIXING.
FOR CLEANING, YOU MAY USE A DAMP CLOTH (NOT WET)
DO NOT USE POLISH, DETERGENT OR CHEMICAL CLEANERS.
THE SURFACE OF THIS ITEM IS NOT HEAT RESISTANT. ALWAYS USE A
PLACE MAT UNDER HOT OR COLD ITEMS TO PREVENT MARKING.
ASSEMBLY INSTRUCTIONS
FOR DOMESTIC USE ONLY
IMPORTANT
SEC/SH/10/18/EU1
PAGE 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Seconique STOCKHOLM 3 + 2 DRAWER CHEST
Summary of Contents for Seconique STOCKHOLM 3 + 2 DRAWER CHEST
- Page 1 SEC/SH/10/18/EU1 STOCKHOLM 3 + 2 DRAWER CHEST ASSEMBLY INSTRUCTIONS DO NOT FOR DOMESTIC USE ONLY IMPORTANT PLEASE READ BEFORE YOU CONTINUE FURTHER THE PRODUCT YOU HAVE PURCHASED WILL GIVE YOU MANY YEARS OF SERVICE IF YOU FOLLOW THE GUIDELINES FOR ITS SAFE ASSEMBLY AND PERIODIC MAINTENANCE AND CLEANING.
- Page 2 SEC/SH/10/18/EU1 (SCREWDRIVER NOT PROVIDED) USE A FLAT HEAD SCREWDRIVER TO TIGHTEN THE CAM NUTS. A QUARTER TURN CLOCKWISE IS ALL THAT IS NEEDED. STEP 1 - PUSH CAM BOLT INTO INSERT STEP 2 - ALIGN THE CAM BOLT WITH THE HOLE AND PUSH TOGETHER UNTIL FLUSH. ( MAKE SURE THE ARROW OF THE CAM LOCK IS POINTING TOWARD ON THE EDGE OF THE PANEL.) STEP 3 - THE HEAD OF THE BOLT GOES INTO THE WIDE MOUTH OF THE CAM LOCK.
-
Page 3: Parts List
SEC/SH/10/18/EU1 PART LIST PARTS LIST PILLAR LEG_LEFT 2 PCS PLEASE CHECK THAT YOU HAVE ALL THE PARTS LISTED BEFORE YOU START ASSEMBLING. IF YOU DO FIND THAT SOMETHING IS MISSING, DO NOT CONTINUE ASSEMBLY, PLEASE CONTACT PILLAR LEG_RIGHT 2 PCS YOUR SUPPLIER IMMEDIATELY. -
Page 4: Hardware List
SEC/SH/10/18/EU1 HARDWARE LIST DOWEL 6 X 30MM 77 PCS SCREW M4 X 50MM 1 PC BOLT M7 X 60MM 4 PCS ANTI-TIP STRIP 2 PCS M4 X 16MM SCREW M3.5 X 12MM 72 PCS 2 PCS PLASTIC CORNER BLOCK 8 SETS M6 X 50MM 10 PCS HANDLE SCREW 19MM... - Page 5 SEC/SH/10/18/EU1 STEP 1 STEP 2 HARDWARE NEEDED: HARDWARE NEEDED: 20PCS 4PCS 4PCS 4PCS STEP 1.1 STEP 1.2 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 5...
- Page 6 SEC/SH/10/18/EU1 STEP 3 STEP 4 HARDWARE NEEDED: HARDWARE NEEDED: 10PCS 3PCS 8PCS 16PCS 8PCS 2PCS 3PCS 2PCS 4PCS FINISHED FRONT EDGE BACK MAKE SURE THE ARROW ON THE CAM LOCK IS POINTING FRONT TOWARD THE HOLE ON THE EDGE OF THE PANEL. Upper Second Hole FINISHED STEP 3.1...
- Page 7 SEC/SH/10/18/EU1 STEP 5 STEP 6 HARDWARE NEEDED: HARDWARE NEEDED: 4PCS FINISHED 16PCS FRONT EDGE 2PCS 9PCS 4PCS MAKE SURE THE ARROW ON THE CAM LOCK IS POINTING Upper Second Hole TOWARD THE HOLE ON THE EDGE OF THE PANEL. FINISHED STEP 5.1 STEP 6.1 First Hole...
- Page 8 SEC/SH/10/18/EU1 STEP 7 STEP 8 HARDWARE NEEDED: HARDWARE NEEDED: ROUND EDGE 10PCS FACING UP ROUND EDGE STEP 7.1 STEP 8.1 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE. PAGE 8...
- Page 9 SEC/SH/10/18/EU1 STEP 9 STEP 10 HARDWARE NEEDED: HARDWARE NEEDED: 28PCS 12PCS 8SETS 13PCS 10PCS DRAWER LEFT & RIGHT STEP 10.1 17&19 DRAWER X 3 STEP 9.1 DRAWER LEFT & RIGHT STEP 10.2 MAKE SURE THE ARROW ON THE CAM STEP 9.2 LOCK IS POINTING TOWARD THE HOLE ON THE EDGE OF THE...
- Page 10 SEC/SH/10/18/EU1 STEP 11.2 STEP 11 HARDWARE NEEDED: 8PCS 4PCS 12PCS 2PCS 4PCS 4PCS LAST THIRD HOLE STEP 11.1 STEP 11.3 FINISHED FRONT EDGE 17&19 THIRD HOLE 17&19 STEP 11.4 17&19 17&19 DRAWER X 2 LEFT & RIGHT THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE.
- Page 11 SEC/SH/10/18/EU1 LAST THIRD HOLE STEP 13 STEP 13.3 HARDWARE NEEDED: 24PCS 12PCS THIRD HOLE 3PCS 18PCS 6PCS FINISHED 6PCS FRONT EDGE 6PCS 6PCS STEP 13.1 STEP 13.4 STEP 13.2 STEP 13.5 DRAWER X 3 THE USE OF POWER TOOLS TO ASSEMBLE THIS PRODUCT WILL INVALIDATE CAUTION : ANY CLAIM AND MAY DAMAGE THIS PRODUCT MAKING IT UNSAFE.
- Page 12 SEC/SH/10/18/EU1 STEP 14 Wall Wall HARDWARE LIST (T) Anti-Tip Strap - 2pcs (U) M4 X 16MM - 2pcs WARNING SERIOUS OR FATAL INJURIES CAN OCCUR FROM FURNITURE TIPPING OVER. TO PREVENT THE FURNITURE FROM TIPPING OVER WE RECOMMEND THAT IT IS PERMANENTLY FIXED TO THE WALL. WALL FIXING ARE NOT SUPPLIED WITH THIS PRODUCT AS DIFFERENT WALL MATERIAL REQUIRES DIFFERENT TYPES OF FIXING DEVICES.
