- Page 1 KP-241 PowerG Wireless Portable Keypad Installation Instructions...
- Page 2 Introduction The KP-241 PG2 is a wireless and portable two-way keypad with a built-in proximity tag reader that is compatible with PowerMaster systems. It enables arming and disarming of the alarm system; initiates emergency, fire, and panic alarms; and controls programmable outputs (PGMs).
-
Page 3: Getting Started
Getting started Table 1: Keypad parts Part Description Figure 1: Keypad parts Disarm button Arm Home button Arm Away button PGM activation button Partition selection Function button Instant arm button Status/Cancel button Emergency button Fire button Panic alarm LED indicator Tag reader Mounting bracket Back tamper magnet... -
Page 4: Inserting The Battery
Inserting the battery Caution! There is a risk of explosion if the battery is replaced by an incorrect type. Figure 2: Inserting the battery 1 Slide out the battery compartment cover. 2 Insert the battery, and ensure correct polarity. 3 Close the cover. Warning! Dispose of used batteries according to the manufacturer's instructions and according to local rules and regulations. -
Page 5: Enrolling Proximity Tags
Enrolling proximity tags You can use proximity tags instead of user codes to arm and disarm the system. A proximity tag can be assigned to each of the users 1 to 8. 1 Enter the Installer menu and select 02: ZONES/DEVICES. 2 Select ADD NEW DEVICES. -
Page 6: Operating The Keypad
Operating the keypad Table 3: Quick reference guide Feature Description Command Arms the system to protect the site perimeter. Movement Press the Arm Home button and enter Arm Home within the interior does not trigger an alarm. your user code or present your tag. Press the Arm Away button and enter your Arm Away Arms the system when you vacate the protected site. -
Page 7: Arming Indications
General indications The following table describes the meaning of LED indications that occur during general use of the keypad: Table 4: General LED indications Indication The command transmits successfully to control panel. This occurs after every input. Green with success tune Operation successful Red with failure tune Operation failed... -
Page 8: Cleaning The Keypad
Cleaning the keypad Clean the keypad using a lint-free cloth or soft wipes. Lightly moisten the cloth or wipes with water, household glass-cleaning agent, or low concentration isopropyl alcohol (IPA). Warning! Do not use cleaning products that contain acids, bleach or corrosive agents. Specifications Table 6: Specifications Feature... -
Page 9: Compliance With Standards
Compliance with standards Europe: EN 300220, EN 300 330, EN 301489, EN 50130-4, EN 50130-5, EN 50131-3, EN 50131-1, EN 62368-1 Grade 2 Class II, EN 50131- 6, Type C. Hereby, Visonic Ltd. declares that the radio equipment type KP-241 PG2 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.visonic.com/download-center. - Page 10 ANY OTHER CAUSE, EVEN IF MANUFACTURER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH the English version shall prevail. DAMAGE. © 2020 Johnson Controls. All rights reserved. JOHNSON CONTROLS, TYCO and VISONIC are trademarks and/or registered trademarks. Unauthorized use is strictly prohibited. D-307872 KP-241 PG2 (Rev 1, 02/20) Email: info@visonic.com...
