- Page 1 User’s Manual Sapphire EDGE-HD Mini PC - 1 - ...
-
Page 2: Product Specifications
1. Product Specifications Item Description CPU AMD APU E450 ® Chipset Hudson‐M1 (A50M) Chip RAM 4GB – DDR3 Storage 2.5'' SATA 250GB / 320GB / 500GB HDD Graphics AMD Radeon HD6320 LAN Built‐in Ethernet supporting 10/100/1000 Mbps WIFI Built‐in WIFI supporting IEEE 802.11 b/g/n VGA x1, HDMI x1, RJ45x 1, USB 3.0 Ports x2, USB 2.0 Ports x2, I/O Audio‐In x1, Line Out x1 Power AC 100~240V 50/60Hz,19v~3.42A 65W Monitor Supplied separately Keyboard/Mouse Supplied separately Dimensions 19.3(L) X 14.8(W) X 2.2(H) cm Weight 530g Operating System Pre‐installed with FREE DOS; Supports Win7/Vista Important information for your safety and comfort Please read these instructions carefully before using the product and save for future reference. Ensure that the Mini‐PC is turned off and disconnected from the mains supply before cleaning ... -
Page 3: Product Overview
2. Product Overview Features No. Item Description The power switch allows you to Power Switch and Power Indication 1 switch the Mini PC ON or OFF. The light light will glow when the power is on Light will glow when the hard disk is 2 HDD Activity Indicator in use 3 VGA port To connect to a VGA monitor 4 HDMI port To connect to an HDMI monitor 5 Rear USB 2.0 Ports To connect to USB devices 6 LAN Port To connect to an Ethernet LAN cable 7 DC Input To connect the power supply ... - Page 4 3. Sapphire Mini PC Setup and Connections To attach the Desktop Stand (1). Feed the thumb screw provided through the hole in the base of the stand (2). Align stand with the base of the Mini PC (3). Hand tighten the screw To connect to a VGA display Connect the VGA monitor or other display device to the 15 pin D‐Sub connector found on the rear of the unit. To connect to an HDMI display / TV Connect the HDMI monitor or other display device to the HDMI connector found on the rear of the unit. To connect to a DVI display (1). Connect the HDMI to DVI adapter included with the Mini PC to the HDMI port found at the rear of the unit. (2). Connect the DVI monitor to the female DVI port on the adapter. To connect USB devices Connect USB devices to the USB ports found both at the rear of the unit and under the cover on the front of the unit. ...
- Page 5 To connect to the network Connect the Ethernet cable from your network switch / router to the RJ45 LAN connector found at the back of the unit. To connect the power adapter Connect the power connector from the supplied power supply to the DC – In connector found on the rear of the unit BEFORE attaching the mains power cable to an AC outlet. To connect speakers or headphones Connect the 3.5mm audio cable to the Audio Out jack found at the rear of the unit. To connect a microphone or other audio source Connect the 3.5mm audio cable to the Line In jack found at the rear of the unit. Note: This Mini PC provides one standard RJ‐45 jack for connecting to a Local Area Network (LAN). Two LEDs are built into the RJ‐45 LAN connector. These LEDs indicate the status of the LAN. LED Color LED state Indicates ...
-
Page 6: Configuring The Bios
4. Configuring the BIOS This chapter provides information on the BIOS Setup program and allows you to configure the system for optimum use. 4‐1 Enter BIOS Setup The BIOS is the communication bridge between hardware and software. Correctly setting the BIOS parameters is critical to maintain optimal system performance. Use the following procedure to change BIOS settings. 1. Power on the computer. 2. Press the Del key when the following message briefly shows upon the bottom of the display during Power On Self Test (POST). Press F1 to continue, DEL to enter Setup. Pressing Del takes you to the BIOS Aptio Setup Utility. Note1: It is strongly recommended that you do not change the default BIOS settings. Changing some settings could damage your computer. Note2: The BIOS options in this manual are for reference only. BIOS screens in manuals are usually the first BIOS version when the board is released and may be different from your purchased motherboard. Users are welcome to download the latest BIOS version from our official website ControlKeys Please check the following table for the function description of each Controlkey. Control Key(s) Function Description / Moves cursor left or right to select Screens / Moves cursor up or down to select items + / ‐ To change option for the selected items <Enter> To bring up the selected screen <F1> To display the General Help Screen <F2> To load previous values for all the settings <F3> To load optimal default values for all the settings ... - Page 7 4‐2 Main Menu When entering the Aptio Setup Utility, the main menu screen appears. This main menu includes the system overview and displays the basic system configuration, such as BIOS information, memory size and system date/time. Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit BIOS Information Set the Date. Use Tab to BIOS Vendor American Megatrends switch between Data Core Version 4.6.4.0 elements. Compliancy UEFI 2.1 Project Version 1A0VU 0.41 x64 Build Date and Time 10/14/2011 15: 12 : 34 Memory Information : Select Screen ...
-
Page 8: Advanced Menu
4‐3 Advanced Menu The Advanced menu items allow you to change the settings for the CPU, USB and other system devices. Press <Enter> to display the configuration options. Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Main Chipset Boot Security Save & Exit Advanced Enables or disable Boot Legacy OpROM Support option for legacy network Launch PXE OpROM [Disabled] devices PCI Subsystem Settings ACPI Settings S5 RTC Wake Settings : Select Screen CPU Configuration Select Item USB Configuration ... -
Page 9: Maximum Payload
Maximum Payload Sets the Maximum Payload size of PCI Express Device or allows the System BIOS to select the value. Options: Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, 4096 Bytes. Maximum Read Request Sets the Maximum Read Request of PCI Express Device or allows the System BIOS to select the value. Options: Auto, 128 Bytes, 256 Bytes, 512 Bytes, 1024 Bytes, 2048 Bytes, 4096 Bytes. ASPM Support Sets the ASPM level, select “Force L0” can force all links to L0 state. Options: Disabled, Auto, Force L0. Extended Synch If select “Enabled”, allows generation of Extended Synchronization patterns. Options: Enabled, Disabled. ACPI Settings Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Advanced Enable ACPI Auto Configuration [Disabled] Enables or Disables BIOS ACPI Auto Configuration. Enable Hibernation [Enabled] ACPI Sleep State [S3 (Suspend to RAM)] Lock Legacy Resources [Disabled] : Select Screen ... -
Page 10: Cpu Configuration
S5 RTC Wake Settings Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Advanced Wake system with Fixed Time [Disabled] Wake system with Dynamic Time [Disabled] : Select Screen Select Item Enter: Select +/‐: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: Save and Exit ESC: Exit Version 2.10.1208. ... -
Page 11: Usb Configuration
PSTATE Adjustment This item allows you to adjust startup P‐State level. Options: PState 0 ~7. PPC Adjustment This item allows you to adjust _PPC object. Options: PState 0 ~2 NX Mode Enables the No‐execute page protection function. Options: Enabled, Disabled. SVM Mode Enables the CPU SVM( Secure Virtual Machine) function. Options: Enabled, Disabled. C6 Mode This item allows you to select C6 State for Nehalem processor. Options: Enabled, Disabled. Cpb Mode This item allows you to disable turbo mode Core Performance Boost. Options: Auto, Disabled. Node 0 Information This field displays the CPU information related to Node 0. USB Configuration Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support; AUTO option disables legacy USB Devices: support if no USB devices are 1 Keyboard, 1 Mouse connected, DISABLED option will keep USB devices Legacy USB Support [Enabled] ... -
Page 12: Device Reset Time-Out
Options: Enabled, Disabled. XHCI Hand‐off This is a workaround for OSes without XHCI hand‐off support. The XHCI ownership change should be claimed by XHCI driver. Options: Enabled, Disabled. EHCI Hand‐off This is a workaround for OSes without EHCI hand‐off support. The EHCI ownership change should be claimed by EHCI driver. Options: Enabled, Disabled. Part 60/64 Emulation Enables I/O port 60h/64h emulation support. This should be enabled for the complete USB keyboard legacy support for non‐USB aware OSes. Options: Enabled, Disabled. USB transfer time‐out The time‐out value for control, bulk, and interrupt transfers. Options: 1 sec, 5 sec, 10 sec, 20 sec. Device reset time‐out Sets USB mass storage devices start unit command time‐out. Options: 10 sec, 20 sec, 30 sec, 40 sec. Device power‐up delay Maximum time the device will take before it properly reports itself to the Host controller. ‘Auto’ uses default values; for a Root port it is 100ms, for a Hub port the delay is taken from Hub descriptor. Options: Auto, Manual. Super IO Configuration Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Advanced Super IO Configuration Set Parameters of Serial Port 0. Super IO Chip Fintek F71808 Restore on AC Power Loss [Always Off] ... - Page 13 EuP Function Enables the EuP (Energy Using Products) function, allows BIOS to switch off some power at S5 state to get system ready for the EuP requirement to reduce power consumption. Options: Enabled, Disabled. H/W Monitor Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Advanced PC Health Status Fan Mode Setting. CPU Temperature : +58 C System Temperature : +44 C CPU Fan Speed : 6024 RPM System Fan Speed : N/A VCC3V : +3.328 V CPU Vcore : +1.304 V +1V : +1.504 V VDIMM : +1.568 V : Select Screen ...
-
Page 14: Onboard Device
Onboard Device Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Advanced Marvell Gigabit LAN [Enabled] Wireless LAN [Enabled] HD Audio Azalia Device [Enabled] : Select Screen Select Item Enter: Select +/‐: Change Opt. F1: General Help F2: Previous Values F3: Optimized Defaults F4: ... -
Page 15: Chipset Menu
4‐4 Chipset Menu The chipset menu items allow you to change the advanced chipset settings. Press <Enter> to display the sub‐menu. Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Main Advanced Boot Boot Security Save & Exit Chipset North Bridge North Bridge Parameters South Bridge : Select Screen Select Item Enter: Select +/‐: Change Opt. F1: General Help F2: Previous Values ... -
Page 16: South Bridge
Bank Interleaving Bank Interleaving is an important parameter for improving overclocking capability of memory. It allows system to access multiple banks simultaneously. Options: Enabled, Disabled. IOMMU Mode IOMMU is supported on LINUX based system to convert 32bit I/O to 64bit MMIO. Options: Disabled, 32MB, 64MB, 128MB, 256MB, 512MB, 1GB, 2GB. Memory Clock Allows you to select different memory clock. The default value is 400MHz. Options: Auto, DDR‐800 (400MHz), DDR‐1066 (533MHz), DDR‐1333 (667MHz). Node 0 Information This filed displays the memory information related to Node 0. South Bridge Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Security Chipset SB CIM Version : 1.1.0.5 Options for SATA Configuration SB SATA Configuration SB USB Configuration SB Clock Spread Spectrum [Disabled] : Select Screen ... - Page 17 4‐5 Boot Menu The Boot menu is used to configure the boot settings and the boot priority. Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Boot Boot Configuration Number of seconds to wait for Setup Prompt Timeout 1 setup activation key. 65535(0xFFFF) Bootup NumLock State [On] means indefinite waiting. Quiet Boot [Enabled] CSM16 Module Version 07.63 Option ROM Message [Force BIOS] ...
-
Page 18: Security Menu
4‐6 Security Menu The Security menu allows you to change the system security settings. Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Save & Exit Security Password Description Set setup Administrator Password. If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter setup. In Setup the user will have Administrator rights. The password must be 3 to 20 characters long. : Select Screen Administrator Password Select Item User Password Enter: Select +/‐: Change Opt. ... -
Page 19: Save & Exit Menu
4‐7 Save & Exit Menu The Save & Exit menu allows you to load the optimal default values for BIOS, and save or discard your changes to the BIOS items. Aptio Setup Utility ‐ Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Save & Exit Security Save Changes and Exit Exit system setup after saving the Discard Changes and Exit changes. Save Changes and Reset Discard Changes and Reset Save Options Save Changes Discard Changes : Select Screen Restore Defaults Select Item Save as User Defaults ... - Page 20 Note: Some older Operating Systems do not support AHCI mode. If the Operating System you try to install does not see the HDD as a valid destination, please go to the <Advanced> page in the BIOS Setup Utility, choose “SATA Configuration” page and set “SATA Controller Mode” to “SATA Mode”. Warnings Do not use this product near water or a heat source such as a radiator. Do not place this product on an unstable stand or surface. If the product falls, it could be seriously damaged. The ventilator on the enclosure is used for air convection and to prevent the equipment from overheating. Do not cover the ventilator Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short‐out parts that could result in a fire or electric shock. Never spill liquid of any kind onto or into the product. To avoid damage of internal components and to prevent battery leakage, do not place the product on a vibrating surface. Keep this equipment away from humidity and high temperature Do not leave the equipment in an unconditioned environment with a storage temperature above 60 C (140 F) or below 0...
- Page 21 REACH Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework Lithium‐Ion Battery Warning Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. CE Mark Warning This is a Class B product, in a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. CE marking for devices without wireless LAN/Bluetooth The shipped version of this device complies with the requirements of the EEC directives 2004/108/EC “Electromagnetic compatibility” and 2006/95/EC “Low voltage directive”. R&TTE Directive 1999/5/EC as attested by conformity with the following harmonized standard: •Article Safety •EN60950 •Article EMC •EN301 489‐1/‐17 •Article Spectrum Usages •EN300 328 WEEE Statement Under the European Union (“EU”) Directive on Waste Electrical and Electronic Equipment, Directive 2002/96/EC, effective from August 13, 2005, states products of “electrical and electronic equipment” no longer may be discarded as municipal waste. Please refer to your original point of purchase for instruction on the correct procedure of discarding as municipal waste. It is the sole responsibility/obligation of the local authorized reseller/distributor of such covered electronic equipment to take back such products at the end of their useful life. For better environmental protection, waste batteries should be collected separately for recycling or special disposal. - 21 - ...
- Page 22 FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: The manufacturer is not responsible for ANY interference, for example RADIO or TV interference, caused by unauthorized modifications to this equipment. Such modifications could void the user’ authority to operate the equipment. - 22 - ...
