Sapphire Audio EDGE-VS Series User Manual

User Manual
Sapphire EDGE-VS Series Mini PC

1. Product Specifications

Item Description
CPU AMD APU Trinity A4
AMD Radeon
Chipset
®
Chipset AMD Hudson-M3 (A70M) Chip
RAM 4GB – DDR3
Storage 2.5'' SATA 320GB / 500GB / 750GB HDD
LAN Built-in Ethernet supporting 10/100/1000 Mbps
WIFI / BT Built-in WIFI supporting IEEE 802.11 b/g/n ; BT 3.0
1x Mini Display, 1x HDMI, 1x RJ45, 2x USB 3.0 Ports,
I/O 4x USB 2.0 Ports, 1x Audio-out, 1x MIC-in,
1x SPDIF-out
Power AC 100~240V 50/60Hz,19v~3.42A 65W
Monitor Supplied separately
Keyboard/Mouse Supplied separately
Dimensions ?? (L) X ??(W) X ??(H) cm
Weight ??g
Pre-installed with FREE DOS;
Operating
Supports Win8/Win7/Vista
System
Important information for your safety and comfort
Please read these instructions carefully before using the product and save
for future reference.
Ensure that the Mini-PC is turned off and disconnected from the mains
supply before cleaning
Do not use liquid or aerosol cleaners, a damp cloth should suffice
Insert the power connector into the Mini PC before plugging the mains
cable into the AC power outlet.
When you need to disconnect power to the equipment, unplug the
power cord from the AC power outlet before removing the power
connector from the Mini PC.
EDGE‐VS Series Mini PC
AMD APU Trinity A8
TM
AMD Radeon
HD7400G HD7600G
1
- -
TM
EN
