APS Auto Parts Specialist IB06EAG7 Installation Instructions

6”,5”,4” running board for 2009-2014 ford f-150 supercrew cab

Installation Instructions for IB06EAG7

Application: For 2009-2014 Ford F-150 SuperCrew Cab

Estimated Time: 1 to 2 hours

by APS Auto Parts Specialist Inc.

For 2009-2014 Ford F-150 SuperCrew Cab

Disclaimer: Instructions intended for persons

aged 18+ please do not attempt without adult

supervision. Instructions are not intended to

replace professional installation. Damage

from improper installation, misuse or

modification to the product voids the

manufacturer's warranty.

(6",5",4")RUNNING BOARD

Rev.20180901

Table of Contents

Need help?

Do you have a question about the IB06EAG7 and is the answer not in the manual?

Page 1 (6”,5”,4”)RUNNING BOARD For 2009-2014 Ford F-150 SuperCrew Cab Rev.20180901 Installation Instructions for IB06EAG7 by APS Auto Parts Specialist Inc. Application: For 2009-2014 Ford F-150 SuperCrew Cab Estimated Time: 1 to 2 hours Disclaimer: Instructions intended for persons aged 18+ please do not attempt without adult supervision.
Page 2 (6”,5”,4”)RUNNING BOARD For 2009-2014 Ford F-150 SuperCrew Cab Rev.20180901 PARTS LIST: Item Description Item Description Running Board(use for left or right) M8 Flat Washers Front/Rear Mounting Brackets M8 Large Flat Washers Driver/Left Center Mounting Bracket（DCM） M8 Lock Washers Passenger/Right Center Mounting Bracket（PCM） M8 Hex Nuts M6X1-20 T-Bolts 8mm Deep Clip Nuts...
Page 3 (6”,5”,4”)RUNNING BOARD For 2009-2014 Ford F-150 SuperCrew Cab Rev.20180901 hardware at this time. NOTE: The cradle on the center mounting Bracket will face the front of the vehicle. 8. Continue along the cab to the rear mounting location. Locate the last (2) mounting holes in the pinch weld towards the back of the cab, (Figures 1 ).
Page 4 (6”,5”,4”)RUNNING BOARD For 2009-2014 Ford F-150 SuperCrew Cab Rev.20180901 Driver Side Installation Pictured 8mm Clip Nut Front Front (Fig 5) Driver/left center mounting location pictured (Fig 6) Driver/left center Bracket 8mm x 30mm Hex Bolt 8mm x 25mm Hex Bolt 8mm Lock Washer (2) 8mm Flat Washers 8mm Large Flat...
