- Page 2 INDEX 1. OVERVIEW DRAWING.........錯誤! 尚未定義書籤。 2. IMPORTANT SAFETY INSTRUCTIONS ..........3 3. GROUNDING INSTRUCTIONS ..............4 4. PRE-ASSEMBLY CHECK LIST ......錯誤! 尚未定義書籤。 5. ASSEMBLY STEPS ..........錯誤! 尚未定義書籤。 6. CAUTION ...............錯誤! 尚未定義書籤。 7. MAINTENANCE ............錯誤! 尚未定義書籤。 8. COMPUTER OPERATION INSTRUCTIONS..錯誤! 尚未定義書籤。 - 1 -...
-
Page 3: Overview Drawing
1. OVERVIEW DRAWING 電子錶 Computer 安全插銷/夾子 Safety Key/ Clip 電源開關 Power Switch 過載保護開關 Circuit Breaker Power Cord 電源線 機台主架 Frame 底座 Base - 2 -... -
Page 4: Important Safety Instructions
2. IMPORTANT SAFETY INSTRUCTIONS When using this product, basic precautions should always be followed, including the following: Please read the instruction carefully before starting to use this product. Danger – To reduce the risk of electric shock： Always unplug this product from the electrical outlet immediately after using and before cleaning the treadmill. -
Page 5: Grounding Instructions
3. GROUNDING INSTRUCTIONS The products must be grounded first. If malfunction or breakdown occurs, grounding will provide a path of least resistance for electric current to reduce the risk of electric shock. The product is equipped with a cord having an equipment-grounding conductor and a grounding plug. -
Page 6: Pre-Assembly Check List
4. PRE-ASSEMBLY CHECK LIST Description ITEM Description ITEM Computer Console Hex Screw M8xP1.25x15 Frame Washer Ø8xØ16x1.5t Left Handrail Hex Screw M8xP1.25x60 Right Handrail Philips Screw M5xP0.8x18 Cover SILICON Decoration Cover (Left) Hex Wrench 5mm(80mmx80mm) Decoration Cover (Right) Hex Wrench 6mm(80mmx80mm) Towel Safety Key/Clip - 5 -... -
Page 7: Assembly Steps
5. ASSEMBLY STEPS Two persons are required to finish the assembly steps. (Caution!! Please follow exactly the assembly steps below to avoid injury.) 1. Tighten the lower Control Wire of Frame (B) with the Guide Thread attached in Right Upright (D) , then pull it into the Upright and clip the control wire with Wire Clip, then insert it into the Upright as the direction the round picture shows in the... - Page 8 4. After finished the above steps, insert Cover (E) to the above of Handrail. After that, fix the left and right Decoration Cover (F, G) to Frame as the right drawing shows and tighten with Philips Screw (d). - 7 -...
- Page 9 6. Caution Note: Thy Cylinder contains high pressure gas. Please avoid crash with other objects to avoid danger. Note: If the Cylinder is hit, it might be damaged and cause the usage not smooth. The treadmill might fall while folding. This treadmill has the foldable mechanism for storage.
-
Page 10: Maintenance
7. MAINTENANCE 1. If the belt tends to move off the center, stop the treadmill. Take the Hex Wrench 6mm and adjust the Hex Screw in the Rear End Cap. For example, if the running belt is moving towards the left side, tighten the left Hex Screw about 1/4 turn(clockwise);... - Page 11 8. COMPUTER OPERATION INSTRUCTIONS General Operation Turn on the treadmill Put the safety key in the recess of the console. The beeper will sound. At this time, all windows will display the values. The preset values are 0，not blinking which means this treadmill has entered start/ready status. Under this status, user can hold the grip pulse sensor to detect heart rate value directly.
- Page 12 ** It will show the relationship that whether the amount of the running is adequate under different age and heart rate. OVER MIDDLE (Age) 1. Press to start treadmill, the treadmill will start with a speed of 1.0km/hr, at this time press to increase/ decrease speed (or you can press to control the speed) ,when press...
- Page 13 ＂ to II. MODE Operation Instruction (Under Function Selection Mode, press “ switch among MANUAL, P1~P5 and HRC LED. Under this mode ,you can set the time and distance freely, the operation method is shown below: ，and you will see the MANUAL LED light linking, press 1.1.
- Page 14 Range of time ： 5~99(min) Press and the treadmill will run according to the pre-set value of the program’s the speed and angle of program’s 12 segments will change circularly according to the pre-set values. Every segment will last for 1 minute, when the time is reached, the speed and angle value will change directly.
- Page 15 Refer to the pre-set parameters of PROGRAM ： - 14 -...
- Page 16 - 15 -...
- Page 17 III. Body fat mode： 1. Under START/READY condition, press , you can see the Body Fat LED light is blinking, present you are in to Body Fat function. When you choose this function, program will require you enter following values. ◎...
- Page 18 HRC function： (This function must be attached with heart beat to finish) 2.1. The program aims to exercise heartbeat. When operating, the heartbeat value is equal to the pre-set value, the angle and speed will keep steady to maintain the heartbeat value in certain range to achieve the exercising effect.
- Page 19 **The chart below will show the relationship between different age and heart rate of this product of HRC function： Pre-set Pre-set Pre-set Pre-set - 18 -...
