Align the pointer to the burn mark
The Red Dot Pointer is in the rear
of the machine, mounted to the
right end of the laser tube.
Pointer Adjustment Screws
Laser Alignment, Epilog 8000 Series
14
Next
Tip: Small adjustments can make large changes! Always make Very Small Adjustments.
