Manufacturer is not responsible for negligent use of vehicle with mud flaps installed, including
over-tightening of screws and bolts causing damage to vehicle or mud flaps.
TOOLS REQUIRED-
OR
7mm Open Wrench or
Socket Wrench
FLAPS & BRACKETS
(1)Flap Assembly,
Front, DS
Brace, DS
Rear
Part #759977
PARTS BAG #766178
a) (4) Hex Bolt, SS
M6, x 35mm, 18-8
Part #012028
e) (4) Washer, Lock
¼" Helicoil, SS
Part #024000
May 13, 2020
Raptor Front Install Sheet
IMPORTANT:
8mm Open Wrench or
Socket Wrench
(1)Flap Assembly
Front, PS
b) (6) Hex Bolt, SS
M4.2 x 1", Black
Part #016041
f) (4) Nut, Hex
M6 – 1, SS
Part # 025022
2017-2019 Ford Raptor
Mounting Diagram & Instructions
OR
(2) Washer Plate
Rear
Part #759979
Brace, PS
Rear
Part #759978
c) (8) Washer, Flat
0.281" x 1", Alum.
Part #018052
g) (2) Expansion Nut
#8/10, Nylon, Blk
Part # 054044
Mud Flap Set, Rear
Kit# GCR42R
OR
10mm Open Wrench or
Socket Wrench
(2) Backing Plate
Rear
Part #759976
d) (6) Washer, Flat
0.265" x 0.625" Nylon
Part #054071
Page 2
Advertisement
Table of Contents
Related Manuals for Truck Hardware Gatorback GCR42R
Summary of Contents for Truck Hardware Gatorback GCR42R
- Page 1 2017-2019 Ford Raptor Mud Flap Set, Rear Mounting Diagram & Instructions Kit# GCR42R IMPORTANT: Manufacturer is not responsible for negligent use of vehicle with mud flaps installed, including over-tightening of screws and bolts causing damage to vehicle or mud flaps. TOOLS REQUIRED- 7mm Open Wrench or 8mm Open Wrench or...
- Page 2 INSTALLATION (For ease of installation it is suggested that the wheel be removed) 1. Before you install your Mud Flap Set, see the diagram and parts list for all necessary parts. 2. Remove the (2) factory screws on the inside of the fender and one factory push pin from the underside of the fender. 3.
