- Page 5 H38B; H38B...
- Page 6 H38B: front which allow adjustment for the camera positioning. The sliding distance is 52mm. H38B; 3/8" spare screw is installed on the platform as shown. Use these screws for additional reinforcement. Attaching the camera to the head: Loosen the sliding plate lock.
- Page 7 D: Adjusting of sliding plate If the camera tilts to the backward or forward, adjustment is needed to shift the sliding plate front or behind. The head may tilt while adjusting the sliding plate. Keep hold of the camera to ensure it does not fall off. Hold the camera and loosened the sliding plate lock.
- Page 8 Firmly tighten the pan lock, if locking is necessary. Firmly tighten the tilt lock, if locking is necessary.
