Summary of Contents for Wave Italy IMPETUS
- Page 1 WAVE IMPETUS WAVE FORCE Pedal Set for Virtual Simulation Installation, use and maintenance manual...
-
Page 2: Table Of Contents
Accelerator ................... 14 Warranty terms .................. 31 Brake ..................... 15 Copyright ..................... 31 Clutch (WAVE IMPETUS set with 3 pedals) ......15 Disposal ....................31 Clutch (WAVE FORCE set with 2 pedals) ....... 16 Customer Services contacts............31 Functional test ................17... -
Page 3: Manual Information
Dear customer, slightly to the characteristics of the product. Any substantial thank you for choosing the quality and professionalism of Wave S.r.l. changes to the product will in any case be accompanied by Our virtual simulation pedal set is designed to ensure an in- appropriate documentation to be integrated in this manual. -
Page 4: Equipment
Equipment The pedals contained in the package will differ depending on Clutch pedal the configuration chosen upon purchase. Brake pedal The brake pedal can be configured according to your driving Accelerator pedal style by mounting internal modules that modify the pedal USB connection cable feedback. - Page 5 5 - EN...
-
Page 6: Product Description
Product Description WAVE IMPETUS pedal set 3-pedal set for virtual simulation made entirely of anodised aluminium for maximum movement accuracy, long service life and a high level of reliability. The pedal set features the complete configuration of the device with accelerator, brake and clutch. -
Page 7: Installation
Installation Base assembly The pedals must be installed on a solid support base that does M6x16 M6x20 Ø6 Ø6x18 not compromise the ergonomic characteristics and accuracy of x 10 x 10 the product. The base supplied features guides used to position the pedals according to a set or customised distance according to cus- tomer comfort. -
Page 8: Assembly Of The Additional Heel Pad Support
Side supports are changeable to allow locating the fixing trails on the pedestal, either inwards or outwards. Assembly of the additional heel pad support An additional support for assembly on the heel pad is provided M6x16 for driving in greater comfort. It improves the position of the foot by bringing it further forward. -
Page 9: Installation Heights Of The Base
Installation heights of the base 15 mm 250 mm The holes in the base shown in the figure are for installation on a simulation structure or on fixed supports. • View from above: pedal set with assembly of the set sup- ports with flaps facing inwards • View from below: pedal set with assembly of the set sup- ports with flaps facing outwards... -
Page 10: Pedal Assembly
Pedal assembly Mount the pedals using the screws provided. The base features 2 types of guides to install the pedals. The first type, featuring multiple slots, ensures optimal positioning of the pedals according to experience and the tests on the pedal set conducted by Wave S.r.l .;... -
Page 11: Customised Base
Customised base 40 mm 40 mm 40 mm The picture shows the drilling spaces for the installation of the pedals, in the event that the user wants to create a personal- ised support base. Maximum product customisation freedom allows the user to space out the pedals as needed for personal n°9 fori Ø6mm comfort and ergonomics. -
Page 12: Pedal Connections
Pedal connections The pedal set is equipped with a handy interface card, located on the accelerator pedal, which ensures the connection be- tween the pedals and the computer. The board has a cover with slots for connecting the cables. Do not remove the cover to connect the cables. • Connect the clutch pedal (1) to the board, as indicated in the drawing. -
Page 13: Pedal Calibration
Pedal calibration The screens on the monitor may differ slightly from those shown in the picture. To calibrate the pedals proceed as follows: • Access the “Windows” menu, through the icon on the tool- bar, and select Control panel. • Select Devices and Printers. WAVE Pedals Pro (a) is available among the recognised devices. -
Page 14: Settings And Calibration
Settings and calibration • Click on Next (a) to go to the next screen. • Click on Next (b) to go to the next screen. • Take your seat in the simulator and place your feet on the respective pedals. • Without pressing the pedals, click on Next (c) to go to the next screen and skip the calibration for z-axis. -
Page 15: Brake
(f ) and then on Driving software. • Release the brake pedal and click on Next (g) to go to the next screen. Clutch (WAVE IMPETUS set with 3 pedals) The third axis is to be calibrated is the one for the clutch (z-rota- tion). -
Page 16: Clutch (Wave Force Set With 2 Pedals)
• Release the clutch pedal to calibrate the minimum point of travel. • Without pressing the pedals, click on Next (i) to go to the next screen. Clutch (WAVE FORCE set with 2 pedals) If the clutch axis is no connected could show some bouncing or spike (l). -
Page 17: Functional Test
• Click on End (o) to complete the calibration process. If a new calibration is required for any reason, you can restore the default values by clicking on Restore default (p). Functional test • Go back to the Properties screen and scroll the Test window (a). -
Page 18: Pedal Adjustment
Pedal adjustment The pedals feature a variety of adjustments that allow the cus- tomer to find the right driving position. Accelerator pedal adjustment The pedal can be adjusted in 2 positions. +/-10° variation of the static position of the pedal. “Fine”... - Page 19 The preload of the pedal force can be adjusted in two positions, from the softest to the hardest as shown in the picture by the direction of the arrow. Footboard position adjustment. 19 - EN...
-
Page 20: Brake Pedal Adjustment
Brake pedal adjustment Setting the brake with the kit for alternate configuration. • Disconnect the brake connector from the interface card. • Disconnect the brake cylinder from the pedal. • Open the rear cover. • Remove the rod and spring unit from the cylinder. The Configuration kit is composed by a red plastic spacer which, if installed within the group of springs, modifies the feedback and hardness of the brake pedal. - Page 21 • Connect the brake cylinder to the pedal. • Reconnect the brake connector to the interface card. The mechanical brake pedal reaction system is designed according to a specific N/mm law which varies depending on the spring pack fitted, thus increasing the realism and the perceived braking quality.
-
Page 22: Clutch Pedal Adjustment
Clutch pedal adjustment The pedal can be adjusted in 2 positions. +/-10° variation of the static position of the pedal. “Fine” adjustment: 12.5° micrometric setting of the pedal position through the threaded strut. The operating force applied (A) on the clutch and the cam effect (B) can be adjusted according to 13 different values, from the softest to the hardest as shown by the direction of the arrows. -
Page 23: Suspended Pedal Set Base Accessory
Suspended pedal set base accessory Equipment Lower side supports for base Upper side supports for base Heel backing plate Structural beam Package with required hardware Base for pedals Base angle pieces The suspended pedal set base accessory, sold separately, makes it possible to further personalise the style of driving and comfort of use. -
Page 24: Assembly Of The Suspended Pedal Set Base
Assembly of the suspended pedal set base Below is the standard assembly procedure for a gaming posi- M6x16 Ø6 tion fixed at the adjustment midpoints. x 12 • Assemble the heel pad supporting plate on the lower side supports using the nuts and bolts shown in the figure. The flaps of the side supports must face outwards. - Page 25 • Assemble the upper side supports on the lower side sup- ports using the nuts and bolts shown in the figure. M6x16 M6x20 Ø6 x 10 x 28 x 14 The flaps of the side supports must face outwards. • Pre-assemble the pedal base on the angular parts using the nuts and bolts shown in the figure, paying attention to the assembly side.
-
Page 26: Installation Heights Of The Base
Installation heights of the base 25 mm 206 mm 206 mm The holes in the base shown in the figure are for installation on a simulation structure or on fixed supports. Do not use the product for purposes other than those relat- ing to virtual simulation. -
Page 27: Pedal Assembly
Pedal assembly Assemble the pedals as instructed in the previous chapters. Turn the foot supporting plates to ensure comfort when driv- ing. • Remove the foot supporting plates. • Remove the supports of the foot supports on the brake ped- al and accelerator. -
Page 28: Adjusting The Heel Pad Supporting Plate
Adjusting the heel pad supporting plate Adjusting the height of the supporting plate at 3 points. The position must be at the same height on both sides. Adjusting the distance from the user at 3 points. The position must be the same on both sides. Remove the screws as instructed in procedure “1”. -
Page 29: Adjusting The Angle Of The Pedal Set
Adjusting the angle of the pedal set The following operations must be carried out in the same way on both sides: • Loosen the screws (1) and (2). • Remove the screw (3). The upper part of the pedal set could drop suddenly down to the bottom of the slot when removing the screw to release the second side. -
Page 30: Technical Data
Technical data Maintenance Power supply voltage: Wave S.r.l. pedals do not require any particular maintenance. Power consumption: 2.5 W The product user should remove dust from the pedal once a Operating temperature: between 5°C and 32°C month using a soft, clean cloth. Percentage of relative humidity: between 20% and 90% Product compliance... -
Page 31: Warranty Terms
Warranty terms The warranty can only be enforced by the original purchaser and is not transferable. This product is guaranteed by the manufacturer for a period of 24 months from the date of purchase if the purchaser is an in- Copyright dividual. - Page 32 Wave s.r.l. - Via del Risorgimento ,8 41053, Maranello (MO), Italy Tel. 0536-1702627 info@waveitaly.com...
