Soonfire MX Series Quick Start Manual

Advertisement

Quick Links

Any questions, please welcome here.
We will reply you within 12 hours included
the weekend.
Tail switch
1.Tail switch for turning on /off the
flashlight directly
2.Side switch for mode changing
BATTERY LEVEL INDICATION
Blue constant on:saturated
Blue flashes:sufficient
Red constant on:poor
Red flashes:critical
(The flashlight will automatically jump
to the lowest brightness mode)
Side switch
4
Powered by one 18650 battery or 2 x CR123A
Please tightening up the End Cap
and the Body before you use it
or recharge the flashlight.
Using:
1. Half press the tail switch to enter the tactical
lighting mode, release the tail switch to exit.
2. Fully press the tail switch to enter the illumination
mode, click the side switch to adjust the brightness:
micro-low-middle-high-ultra brightness in cycle.
3. Press the side switch for 1.5 seconds to enter the
Strobe mode, then click the switch to enter the SOS
mode and the Slow Flash mode. Press the side switch
for another 1.5 seconds to go back to the illumination
mode.
4. Quickly double-click the side button to directly
change to the ultra-bright illumination mode.
5. Turn off the flashlight and memorize last used
illumination mode.
2
To avoid accidental activation, a very slight
2mm loose the body can disconnect the
battery to the tail cap and completely
lockout the light.
Please be sure to recharge the flashlight
once within every three month.
1
3
5

Advertisement

loading
Need help?

Need help?

Do you have a question about the MX Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Soonfire MX Series

  • Page 1 Any questions, please welcome here. Powered by one 18650 battery or 2 x CR123A Please tightening up the End Cap We will reply you within 12 hours included and the Body before you use it the weekend. or recharge the flashlight. Using: 1.
  • Page 2 Charging Charging When the flashlight is in charging status, 1. With the flashlight on flashlight will automatically turn off and 2.Plug in the Micro USB Cable the red indictor at the switch position blinks once every 1.5 seconds. ITS Smart Temperature Control System Charging NOTE: When you plug in usb cable,the indicator in side switch will show a rapid dim fast-flashing...
