MODEL SOUNDS ShockWave 2 Hardware Reference Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

ShockWave 2 Sound Module
Version 4.1.3 Hardware Reference Manual
Date: November, 2018
TM
© Model Sounds
Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ShockWave 2 and is the answer not in the manual?

Questions and answers

Related Manuals for MODEL SOUNDS ShockWave 2

Summary of Contents for MODEL SOUNDS ShockWave 2

  • Page 1 ShockWave 2 Sound Module Version 4.1.3 Hardware Reference Manual Date: November, 2018 © Model Sounds Inc.

  • Page 2: Table Of Contents

    What is a .sfx7 file? ..........................9 File Structure On The ShockWave 2 microSD Card ................10 CHAPTER 3 – CONNECTING THE SHOCKWAVE 2 MODULE TO YOUR PC ..........11 Transferring files Between the PC and the ShockWave 2 Sound Module ..........12 CHAPTER 4 –...
  • Page 3 Switched Outputs for Smoker fan Control ................... 33 CHAPTER 11 - MISCELLANEOUS ....................... 35 Updating the Firmware in the ShockWave 2 Module ................35 Setting Low Battery Voltage Alarm Sounds ..................35 What Do The Red/Green LEDs Mean? ....................36 Where Are Hardware Settings Stored? ....................

  • Page 4: Table Of Figures

    TABLE OF FIGURES Figure 1: ShockWave 2 Sound Module Layout ................... 4 Figure 2: Wiring for Single Throttle with Separate Receiver Battery ............13 Figure 3: Wiring for Single Throttle Using ESC BEC ................... 14 Figure 4: Wiring for Separate Receiver Battery and Separate Sound Module Battery ......15 Figure 5: Wiring for Dual Motors/ESCs/Throttles with Separate Receiver Battery .........

  • Page 5: Chapter 1 - The Basics - Getting Started

    CHAPTER 1 – THE BASICS – GETTING STARTED SHOCKWAVE 2 SOUND MODULE LAYOUT Figure 1: ShockWave 2 Sound Module Layout Mini-USB Port MicroSD Card Slot Button 1 LEDS (Used for Optional Button Throttle1 Setup) Balance Control Button 2 (Used for Optional...
  • Page 6 Main Battery negative 4.5Volts – 26 volts Do NOT reverse Battery leads!! CAUTION WHEN WIRING : The power and speaker connections on the ShockWave 2 are interchanged from the original ShockWave module. Take care when connecting the battery and speakers! HEADER 2 Detail...

  • Page 7: Mounting The Module

    3. The SPKR terminals MUST NOT be connected to anything other than the appropriate loudspeaker for the supply voltage used. 4. The ShockWave 2 sound module receives its power from the receiver battery through the throttle cable. The ESC (without a BEC) can be connected to the right-hand set of THTTL1 pins to receive its signal from the receiver, thus avoiding the necessity of a Y servo lead to connect both the ESC and the sound module to the receiver throttle output.

  • Page 8: Correct Switch-On Sequence For Transmitter/Receiver/Sound Module

    APPLYING POWER TO THE SHOCKWAVE 2 SOUND MODULE The ShockWave 2 module’s low-level circuitry can be powered using two methods. 1. From the R/C receiver through the THTTL1/2 or SOUND1/2 cables. 2. From the USB port when connected to a PC.

  • Page 9: Why Do I Have To Wait So Long For The Leds To Stop Flashing

    2.4GHz receivers. If your receiver stabilizes much faster, you can reduce this wait time down to as short as one second using the SFXPC4.1.3 Software in its Control Panel->Hardware Tab. ShockWave2-4.1.3 Hardware Manual Page 8 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 10: Chapter 2 - The Microsd Card And .Sfx7 Files

    THE SHOCKWAVE 2 SOUND MODULE AND ITS MICROSD CARD The ShockWave 2 microSD Card connector is a push-push type, i.e. you push the card in to insert and lock it and push it again to release the card for removal. When inserting the microSD Card, make sure it is pushed fully home so that the latching mechanism prevents it from accidentally being removed.

  • Page 11: File Structure On The Shockwave 2 Microsd Card

    FILE STRUCTURE ON THE SHOCKWAVE 2 MICROSD CARD The files on the ShockWave 2 microSD Card must be in a certain format and structure. In the microSD Card Root Folder there is the following file : SELECT_YOUR_SOUNDSET_HERE.txt. This file should contain two lines as follows: One line naming the folder containing the .sfx7 file you wish to use.

  • Page 12: Chapter 3 - Connecting The Shockwave 2 Module To Your Pc

    CHAPTER 3 – CONNECTING THE SHOCKWAVE 2 MODULE TO YOUR PC You DO NOT need to connect the ShockWave 2 sound module to a PC in order to use it or set it up – it is fully configured and ready to use when you receive it. If you want to change any of its many configurable settings or change the sounds then you will need to connect it to a PC and install the optional SFXPC4.1.3 Windows only software application.

  • Page 13: Transferring Files Between The Pc And The Shockwave 2 Sound Module

    The ShockWave 2 module conforms to the USB2.0 Full Speed (12MBits/sec) specification. If you save files to the microSD Card whilst it is in the ShockWave 2 module, it will be much slower than when the microSD Card is in the USB card reader which conforms to USB 2.0 High Speed (480MBits/sec) specification.

  • Page 14: Chapter 4 - How To Wire The Shockwave 2 Module

    CHAPTER 4 – HOW TO WIRE THE SHOCKWAVE 2 MODULE WIRING FOR ONE THROTTLE WITH RECEIVER BATTERY Although some modellers favour using their ESC BEC (Battery Eliminator Circuit) to power their receiver, we do not recommend that set-up for high power systems. Depending upon the wiring, currents involved, and the quality of the ESC BEC, it can introduce radio interference on the receiver power leads.

  • Page 15: Wiring For One Throttle - Without Receiver Battery

    In all cases, please heed the notes (4) on page 5 regarding using the right hand THTTL pins to feed the ESCs only, not the other way round. Wiring diagram on next page … ShockWave2-4.1.3 Hardware Manual Page 14 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 16: Figure 4: Wiring For Separate Receiver Battery And Separate Sound Module Battery

    This arrangement is also recommended whenever the motor has a very high current draw so as to isolate the sound system from the spiky, interference prone motor wiring. ShockWave2-4.1.3 Hardware Manual Page 15 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 17: Wiring For Two Throttles And Two Engine Sounds

    In all cases, please heed the notes (4) on page 5 regarding using the right hand THTTL pins to feed the ESCs only, not the other way round. ShockWave2-4.1.3 Hardware Manual Page 16 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 18: Chapter 5 - Volume/Balance Controls And External Amplifiers

    SOUND2 signal pins from 0 – +2.5 Volts. You can connect an external potentiometer to the SOUND2 signal pins to supply a variable 0 – +2.5 Volts with respect to GND or the –VE battery connection. ShockWave2-4.1.3 Hardware Manual Page 17 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 19: Connecting To An External Amplifier

    ShockWave 2 module and its loudspeakers. This means that you need all four loudspeakers to be pushing or pulling air at the same time. It would not help if the ShockWave 2 speakers (or exciters) were pushing air while the external amplifier speakers were pulling air, as they would be fighting against each other to produce the sound.

  • Page 20: Chapter 6 - Calibrating The Shockwave 3 Throttle Inputs

    The ShockWave 2 module makes this job easy for the average user by measuring the incoming throttle pulse width at the time the red/green LEDS stop flashing and using that as the neutral or OFF throttle pulse.
  • Page 21 6) If you are using a second throttle input (optional), then repeat steps 2-5 but use BUTTON2 and the transmitter Throttle2 stick instead. The green LED will flash TWICE to indicate that Throttle2 neutral or OFF position has been captured. ShockWave2-4.1.3 Hardware Manual Page 20 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 22: Chapter 7 - How To Control The Sounds

    ON position to switch sound N On. Move it back to its OFF position to switch sound N Off. You set which sound is assigned to that switch using the SFXPC4 Control Panel->Hardware Tab – see the SW manual. ShockWave2-4.1.3 Hardware Manual Page 21 of 40 Published: November, 2018 © Model Sounds Inc.
  • Page 23 4. Move stick quickly full backwards = Sound 4 ON; 5. Which specific sounds are played for Sound 1/2/3/4 is programmable using the SFXPC4 SW. 6. Proportional R/C mode is always latched action. ShockWave2-4.1.3 Hardware Manual Page 22 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 24: Using Mechanical Switches Or Logic Level Voltage Inputs

    THROTTLE CONTROLS The ShockWave 2 module can be used with either a forward only throttle (for model airplanes or helicopters) or a forward and reverse throttle (for model boats, tanks and trains). This mode is automatically selected and stored during the Throttle1/2 Setup phase (see next).

  • Page 25: Throttle1 And Throttle2 Setup

    This can be set in the SFXPC4 Windows Application Control Panel->Hardware Tab as detailed in the SFXPC4SWManual.pdf document in the Manuals folder on the microSD Card. ShockWave2-4.1.3 Hardware Manual Page 24 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 26: What Are The Two Buttons Used For

    The Analog input voltage can exceed 2.2V, and can accept up to +12Volts relative to GND, but only the first 2.2V portion will be of use, as that voltage is mapped to an "equivalent maximum pulse width" of 2000µs. ShockWave2-4.1.3 Hardware Manual Page 25 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 27: Controlling The Engine Sounds

    For both types of throttle (forwards or forwards/reverse), nudge the throttle control forwards a little (to step 1) and the corresponding engine sound will start playing. If there is a separate engine start-up ShockWave2-4.1.3 Hardware Manual Page 26 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 28: Starting Up Jet/Turbofan/Turboprop/Helicopter Sounds

    ShockWave2-4.1.3 Hardware Manual Page 27 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 29: Chapter 8 - Special Provisons For Model Tanks And Helicopters

    Transmitter instead of nudging the throttle stick forward a notch or two. ShockWave2-4.1.3 Hardware Manual Page 28 of 40 Published: November, 2018 © Model Sounds Inc.
  • Page 30 This is not the default configuration has to be requested at the time of ordering. Not all helicopter engine/ rotor wash sounds are suitable for this. ShockWave2-4.1.3 Hardware Manual Page 29 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 31: Chapter 9 - Which Loudspeakers To Use

    It is permissible to use to use two 4 Ohm speakers in series only, not in parallel. This will allow the ShockWave 2 sound module to be used on a 6S LiPo where it will be able to deliver its maximum output power.

  • Page 32: Chapter 10 - How To Use The Led Switched Outputs

    LEDs are flashing. The LEDs may be supplied by the same receiver power that supplies the ShockWave 2 module, or another positive voltage up to the maximum 30V rating. These switched outputs are rated at 1 Amp maximum each or 4 Amps for all switched outputs together.

  • Page 33: Using Optional Separate Battery To Power Leds

    If using the receiver battery, connect the switched loads or LEDs to H2 pin 2 or 5 on the module which carries the receiver battery voltage. The LEDS MUST HAVE A SERIES RESISTOR (EACH) TO LIMIT THEIR CURRENT – see the article LEDSeriesResistors.pdf in the Articles folder on the ShockWave 2 microSD Card.

  • Page 34: Caution - Do Not Use These Outputs To Drive A Motor Directly

    NOTE: these diodes must be wired with very short leads directly across the switched outputs – see this photo – this photo is for the ShockWave 2 module, not the older Shockwave/SFX7.0 module. The diode’s action will not be effective if you use long wire lengths.

  • Page 35: Figure 8: External P-Channel Mosfet Transistor For Heavy Currents

    Source 470 Ohm ½ Watt 50V 1A Gate Schottky Diode P-CHANNEL MOSFET Drain E.G. FAIRCHILD FQPF27P06 Optional Secondary Battery Motor ShockWave Switched Ouput System Ground ShockWave2-4.1.3 Hardware Manual Page 34 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 36: Chapter 11 - Miscellaneous

    UPDATING THE FIRMWARE IN THE SHOCKWAVE 2 MODULE Firmware is the program code that runs in the processor chip on the ShockWave 2 module. The ShockWave 2 module features a microSD Card Bootloader program that is a separate small program that runs in a protected area of the microcontroller’s FLASH program memory.

  • Page 37: What Do The Red/Green Leds Mean

    The firmware has halted, i.e. has steady “crashed”. The sound module is inoperable until re-powered up. May also mean low receiver battery voltage – check battery voltage. ShockWave2-4.1.3 Hardware Manual Page 36 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 38: Where Are Hardware Settings Stored

    By default, hardware mode settings, except those above, are stored in a special section of the .sfx7 file that the ShockWave 2 module opened when it was powered up. That is convenient if you want the hardware settings to travel along with the sounds.

  • Page 39: Chapter 12 - Technical Specifications

    Two Throttle outputs can drive ESCs directly avoiding need for a Y servo lead. Second Throttle input can be used as a third SOUND Select input if not needed for second engine sound. ShockWave2-4.1.3 Hardware Manual Page 38 of 40 Published: November, 2018 © Model Sounds Inc.

  • Page 40: Technical Specifications (Continued)

    4. Move stick quickly full backwards = Sound 4 ON; 5. Which specific sounds are played for Sound 1/2/3/4 is programmable using the SFXPC4 SW application. 6. Proportional R/C mode is always latched action. ShockWave2-4.1.3 Hardware Manual Page 39 of 40 Published: November, 2018 © Model Sounds Inc.
  • Page 41 INDEX analogue input, 25 starting Up Jet/Turbofan/Turboprop/Helicopter analogue voltage, 25 Sound files, 27 Applying Power to the ShockWave 2 Sound Stopping The Engine Sounds, 27 Module, 7 Supply Voltage, 7, 38 Automatic Throttle Setup, 19 Switched outputs are designed for small loads –...
