Installation, Operating and Servicing
Instructions
Electric Fume Filtration Units
L3, L4
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 346 ECN 3607
Page 1 of 8
Advertisement
Table of Contents
Related Manuals for Lincat L3
Summary of Contents for Lincat L3
- Page 1 Installation, Operating and Servicing Instructions Electric Fume Filtration Units L3, L4 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 346 ECN 3607 Page 1 of 8...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
1310 40.0 CHECK LIST OF ENCLOSURES Warranty card Instructions manual Aluminium filters (L3 x 2, L4 x 3) Carbon filters (L3 x 2, L4 x 3) Fixing kit INSTALLATION AND COMMISSIONING This appliance must be earthed. An equipotential bonding terminal is provided to allow cross bonding with other equipment. - Page 4 If replacing the plug connect the terminals as follows: Green and Yellow wire Earth Blue wire Neutral N Brown wire Live Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57) Unlatch the front flap and slide out the filters.
-
Page 5: Operating Instructions
Power Ratings Model Amps 0.35 0.45 OPERATING INSTRUCTIONS Only qualified or trained personnel should use this appliance. Connect the appliance to the electricity supply. Turn on the power switch Fig 2 (A). To use the lights, operate switch (B). Front view Underside view Fig 2 IS 346 ECN 3607... -
Page 6: Cleaning
This appliance is fitted with a safety thermostat to cut off the power in the event of a fault. To re-set the safety thermostat, press the button as located in Fig 2, E. CLEANING Do not use a water jet or steam cleaner, and do not immerse this appliance. Clean all panels with warm water and mild detergent, do not use abrasive materials. -
Page 7: Spare Parts List
Part Number Description Used on FA25 FI11 Aluminium filter FI13 Charcoal filter FI15 Foam filter pad LA14 Light L3, L4 PL201 Plug and lead SU15 Latch SW69 On/Off switch SW70 Light switch TH73 Thermostat IS 346 ECN 3607 Page 7 of 8... -
Page 8: Service Information And Guarantee
All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
