Summary of Contents for netsys NM-2000E
- Page 1 ’ ’ ’...
-
Page 2: Copyright
In the interest of improving internal design, operational function, and/or reliability, NETSYS reserves the right to make changes to the products described in this document without notice. NETSYS does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein. -
Page 3: Foreword
& fastest connection between NV-2000E and the devices that connected to it. NV-2000E supports conversion between 10/100/1000 base-TX and 1.25G/2.5G-FX network, and Small form-factor pluggable transceiver is required. NM-2000E also supports 9K bytes jumbo frames pass through which is perfect to utilize in AI, IoT, video streaming application, VOIP, etc. -
Page 4: Safety Warnings
NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 Safety Warnings For your safety, be sure to read and follow all warning notices and instructions before using the device. DO NOT open the device or unit. Opening or removing covers can expose you to dangerous high voltage points or other risks. -
Page 5: Table Of Contents
NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 Table of Contents Copyright ................................2 Foreword ................................3 Safety Warnings ..............................4 Chapter 1. Unpacking Information ........................6 1.1 Check List....................................6 Chapter 2. Hardware Description ........................7 2.1 LED Indicators .................................. -
Page 6: Chapter 1. Unpacking Information
NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 Chapter 1. Unpacking Information 1.1 Check List Carefully unpack the package and check its contents against the check list. Package Contents: 1 x NM-2000E 1 x QR code for user’s... -
Page 7: Chapter 2. Hardware Description
NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 Chapter 2. Hardware Description This section describes the important parts of the converter. It features the front panel and rear panel. 1. Front Panel: The front panel provides SFP Connector, Ethernet Connector and LED indicators of the converter. - Page 8 NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 2. Rear Panel: The rear panel provides Power DC Jack, mode-switching table and Dip Switch. SFP Slot Mode Selection Table: VLAN (Isolation) Selection Table:...
-
Page 9: Led Indicators
NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 2.1 LED Indicators The NM-2000E Converter has 10 LED indicators. The following Table shows the description. (Table 2-1) Table 2-1 LED Indicators Description and Operation... -
Page 10: Application Diagram
2.2 Application Diagram Even though Fiber optic is a well developed technology, it still can't reach some places due to cost & physical limit. NM-2000E is a media converter that supports data transmission between Fiber optic and xDSL on the end point, which give you a alternative way to extend the bandwidth to Maximum 2.5Gbps without further wiring renovation. - Page 11 NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 Appendix A: Cable Requirements A.1 Ethernet Cable A CAT 5~7 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the Modem. A: 10/100TX cable often consists of four pairs of wires, two of which are used for transmission.
- Page 12 NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...
-
Page 13: Appendix B: Product Specification
NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 Appendix B: Product Specification Key Features and Benefits: Supports 2 x 10/100/1000TX & auto –MDIX for RJ-45 port Supports 1 x 1.25G / 2.5G SFP Slot Supports up to 9K jumbo frames Supports DIP switch for selecting SFP mode &... - Page 14 NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 Specification: Item Description Protocol and Standards : IEEE 802.3u / IEEE802.3ab / IEEE802.3z Ethernet: 1000Base-TX Cat.5 or above UTP Cable Cabling requirements: Fiber Optic: Flexible (Depending on Fiber Transceiver) Modes : SFP 1.25G / 2.5G...
-
Page 15: Appendix C: Troubleshooting
NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 Appendix C: Troubleshooting Diagnosing Giga Media Converter Indicators The Giga Media Converter can be easily monitored through its comprehensive panel indicators. These indicators assist in identifying problems the Media Converter may encounter. - Page 16 NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 System Diagnostics Power and Cooling Problems If the POWER indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply.
-
Page 17: Appendix D: Compliance And Safety Information
NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 Appendix D: Compliance and Safety Information FCC Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a computing device, pursuant to Part 15 of FCC class A rules. - Page 18 NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 proper functioning of your equipment. If they do, you will be notified in advance in order for you to make necessary modifications to maintain uninterrupted service.
- Page 19 NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 FCC Warning This equipment has been tested to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 20: Warranty
NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 as RoHS-Recast or RoHS 2. RoHS 2 includes a CE-marking directive, with RoHS compliance now being required for CE marking of products. RoHS 2 also added Categories 8 and 9, and has additional compliance recordkeeping requirements. -
Page 21: Chinese Sj/T 11364-2014
NM-2000E : 2 x10 / 100 / 1000TX+1.25G / 2.5G SFP Media Converter USER’S MANUAL Ver.A.2 sample. We shall not be liable for incidental or consequential damages. We neither assume nor authorize any person to assume for it any other liability.
