1970 DODGE SUPER BEE
Two Panel Sequential LED Taillight Kit
w/ LED Reverse Installation Guide
Kit Contents:
•
4 LED panels
•
2 Rubber grommets
•
1 Power wire
•
1 driver side LED harness, 24"
•
1 passenger side LED harness, 48"
•
2 LED extension harnesses, 12"
•
8 Mounting brackets
•
1 Crimp terminal kit
Please refer to webiste for full warranty information. DIGI-TAILS is not a licensed Mopar product.
Advertisement
Table of Contents
Related Manuals for Digi-tails 1202670
Summary of Contents for Digi-tails 1202670
- Page 1 1 driver side LED harness, 24” • 1 passenger side LED harness, 48” • 2 LED extension harnesses, 12” • 8 Mounting brackets • 1 Crimp terminal kit Please refer to webiste for full warranty information. DIGI-TAILS is not a licensed Mopar product.
- Page 2 1970 DODGE SUPER BEE LED PANEL INSTALLATION STANDARD Note SEQUENTIAL POSITION POSITION The LED boards are shipped with the slide switch set to Sequential mode. We recommend that all slide switches be set to the same setting (either standard or sequential). Please follow all local laws concerning exterior lighting.
- Page 3 1970 DODGE SUPER BEE LED PANEL INSTALLATION 4. Attach mounting brackets. Both housings will require mounting brackets for the LED panels to attach to. There is one set of brackets for the reverse panels and a larger set for the LED panels. 1.
- Page 4 1970 DODGE SUPER BEE LED PANEL INSTALLATION 5. Plug in extension wires, grommets. Feed the extension wires through the socket hole. Wrap the rubber grommet around the wires and press it into the socket hole. Once the LED panels are in place for good, you will still be able to easily plug and unplug the harness and remove the buckets.
- Page 5 1970 DODGE SUPER BEE WIRE SPLICING INSTALLATION WIRE SPLICING INSTALLATION Wire splicing installation Wire splicing insta Pick a point in the rear body harness between the driver’s side quarter p Pick a point in the rear body harness between th 1.
- Page 6 The LED light kits are designed for best performance when use an electronic no-load flasher. Shown here is an optional electronic no load flasher available from DIGI-TAILS, ( PN 20-F2 ) If you decide to use a stock bimetal flasher, we recommend a standard-duty flasher instead of a heavy-duty flasher.
- Page 7 1970 DODGE SUPER BEE WIRE SPLICING INSTALLATION STOCK REAR BODY HARNESS STOCK HARNESS COLORS. BROWN: GREEN: BLACK ALTHOUGH CLOSED END CONNECTORS ARE INCLUDED, IT IS RECOMMENDED THAT ALL SPLICED WIRES BE SOLDERED TOGETHER FOR BEST CONNECTION RELIABILITY. POWER CONNECTION CONSTANT FUSED POWER SOURCE. (AT DOME LIGHT OR FUSE PANEL) DRAWS LOW CURRENT , LESS THAN AMPS.
