- Page 1 M1 Quick Start guide Beijing Ulink Technology Co.Ltd. www.umacaroon.com About macaroon 1. LCD screen 2. Power Key 3. Operation Key 4. USB Cable 5. Interface for Extended Device 6. Direction Mark for SIM card insertion 7. SIM Card Slot...
- Page 2 10. Micro USB Plug for USB Cable 11. Type A USB Plug for USB Cable 1. WLAN 2. Network 3. Mark for Inserting SIM Card 4. Battery Level 5. Battery 6. Mark for Charging Status 7. Menu The Advantages of Macaroon...
- Page 3 ·Simplify the complex with a revolutionary app. Recharge the device and monitor the usage with just one tap How to use macaroon 1. USB Cable 1) Take out USB cable: It is available once you take it out from the location shown in Pic 1.
- Page 4 1) No support for hot-swap purpose. If it is required to use SIM card, please reboot the device after inserting or extracting of SIM card in the slot of SIM card. 6. Device management: 1) Scan QR code to download macaroon APP, go to register a new account after the set-up.
- Page 5 2) Use macaroon APP to scan the barcode on the device to add and lock the device. 3) Purchase the suitable package in the data mall and ready to use it! 7. About WebUI 1) Connect your macaroon M1 device with your mobile phone or PC device.
- Page 6 The Parameters of macaroon Product Name Ulink 4G LTE mobile router Model macaroon M1 Size 85mm*20.6mm Weight 110g FDD-LTE B1/B2/B3/B4/B5/B7/B8/B12/B17/B18/B19/B20 TDD-LTE B38/B39/B40/B41 Bands WCDMA B1/B2/B4/B5/B8 GSM B2/B3/B5/B8 WLAN Support 2.4G WLAN IEEE 802.11 b/g/n LCD Screen 1.54 inch LCD Pixels...
- Page 7 Maximum Power Level(E-GSM 29.36dBm 900): Maximum Power Level(DCS 1800): 24.65dBm WCDMA Operation Frequency: Band 1 TX:1922.4MHz~1977.6MHz,RX:2112.4MHz~2167.6 Band 8 TX: 882.4MHz~912.6MHz,RX:927.4MHz~957.6MHz Maximum Power Level 24.24dBm (WCDMA Band 1): Maximum Power Level 23.81dBm (WCDMA Band 8): FDD LTE Operation Frequency: Band 1 TX:1922.5MHz~1977.5MHz,RX:2112.5MHz~2167.5 Band 3 TX:1710.7MHz~1784.3MHz,RX:1805.7MHz~1879.3...
- Page 8 Maximum Power Level (Band 7): 22.74dBm Maximum Power Level (Band 8): 23.85dBm Maximum Power Level (Band 20): 23.74dBm TDD LTE Operation Frequency: Band 38 TX:2572.5MHz~2617.5MHz,RX:2572.5MHz~2617.5 Band 40 TX:2302.5MHz~2397.5MHz,RX:2302.5MHz~2397.5 Maximum Power Level (Band 38): 23.85dBm Maximum Power Level (Band 40): 23.77dBm 1.
- Page 9 (2) If you still cannot get the internet connection, please contact us through email at service@umacaroon.com and Facebook at www.facebook.com/macaroon.fans 5. What should I do if my device is lost? If your device has been lost incidentally, please contact customer service to freeze your account to avoid making extra expenses.
- Page 10 the lifespan of the device. The device will stop charging automatically when the battery temperature is up to 50℃; it will shut down automatically when the battery temperature is more than 60℃. When using external SIM card, you should cut the SIM card by yourself. The non-standard SIM card cannot be used.
-
Page 11: Rf Exposure Information (Sar)
receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This device complies with FCC SAR exposure limits set forth for an uncontrolled environment. SAR compliance for using the equipment in close proximity to the human body has been evaluated at 5mm. - Page 12 Address of Sales Department: The 5th Floor, East Area, Sinoma International, No. 16 Wangjing North Road, Chaoyang District, Beijing, People's Republic of China Copyright Notice BEIJING ULINK TECHNOLOGY CO., LTD reserves the right of final interpretation of the device regarding the trademark of Ulink and macaroon. For more details Please visit- www.umacaroon.com...
