HIKVISION ISD-SMG318LT-F How To Install

HIKVISION ISD-SMG318LT-F How To Install

Temperature screening metal detector door
Hide thumbs Also See for ISD-SMG318LT-F:

Advertisement

Quick Links

Download this manual
Title:
How to Install and Configure Temperature Screening
Metal Detector Door
Product:
Temperature Screening Metal Detector Door
How to Install and Configure Temperature Screening Metal Detector Door
Introduction
ISD-SMG318LT-F walk-through metal detector, adopting the thermal imagery technology, realizes
non- contact temperature measurement. Face detection function of the camera makes an accurate
positioning of the measurement. The detector also supports metal detection.
Product
Thermal camera
Walk metal detector
Firmware download:
For thermal camera
ftp://hikftp.hikvision.com:400/Product File(Overseas)/01 All Materials of Temperature Screening
Solution/04 Metal Detector Door/06 Technical Material/04 Firmware/
No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788
Product Model
NP-SGXXXLT-F
ISD-SMG318LT-F
© Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved.
E-Mail:
support@hikvision.com
Version:
Note
Please upgrade camera to special firmware version
Metal detector doesn't need firmware
•
www.hikvision.com
v1.0
Date:
3/27/2020
Page:
1 of 13

Advertisement

loading
Need help?

Need help?

Do you have a question about the ISD-SMG318LT-F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION ISD-SMG318LT-F

Summary of Contents for HIKVISION ISD-SMG318LT-F

  • Page 1 How to Install and Configure Temperature Screening Metal Detector Door Introduction ISD-SMG318LT-F walk-through metal detector, adopting the thermal imagery technology, realizes non- contact temperature measurement. Face detection function of the camera makes an accurate positioning of the measurement. The detector also supports metal detection.

  • Page 2: Installation And Wiring

    1. Open package 1) Open package and check if all items are complete as following picture shows © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 3 3. Connect left and right door panel 1) Connect left and right door panel and tighten the screw © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 4 Pay attention to the left and right sign and do not make mistake © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 5 1) Remove trim from turret camera and fix it on the bracket with 3 screws, then put the trim back © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 6 ‘body thermometry –basic settings-target thermometry parameters’, set emissivity as 0.98 and distance as 1m, and click save. © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 7 Enable Face Detection: must check, enable face detection function Display temperature: check, temperature will display on visible light channel © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 8 © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 9 If you want to disable metal detection alarm , you need to set sensitivity of all areas to 0. Use touch screen to set as the following picture shows Click ‘sensitivity’ © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 10 2) log in with account 0000000 3) use“-”to set sensitivity of all area to 0 © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 11 E. How to clear counting numbers 1) Click More on main interface 2) Log in with default account ‘00000000’ © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 12 Temperature Screening Metal Detector Door Page: 12 of 13 3) Click clear to clear people counting numbers © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: •...
  • Page 13 Temperature Screening Metal Detector Door Page: 13 of 13 See Far, Go Further HIKVISION Technical Support © Hangzhou Hikvision Digital Technology Co.,Ltd. All Rights Reserved. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China • Tel: +86-571-8807-5998 • Fax: +1 909-595-0788 E-Mail: • www.hikvision.com...
