- Page 1 AY-U9xxBT Long-Range UHF-RFID Reader with Bluetooth BLE-ID Installation and User Manual S M A R T Models: AY-U915BT AY-U920BT...
- Page 2 ROSSLARE. ROSSLARE reserves the right to revise and change this document at any time, without being obliged to announce such revisions or changes beforehand or after the fact.
-
Page 3: Table Of Contents
Table of Contents Table of Contents Introduction ..................... 7 Installation Kit ....................7 Mounting ......................8 General ......................8 2.1.1 1-Shaped Stand Bracket Side-Loaded ..............8 2.1.2 L-Shaped Stand Bracket Top-Loaded ..............9 2.1.3 Adjusting the Azimuth Angle of Antenna .............. 10 Wiring ...................... - Page 4 List of Figures List of Figures Figure 1: 1-shaped Stand Bracket Side-Loaded ............8 Figure 2: L-shaped Stand Bracket Loaded ..............9 Figure 3: Antenna Angle Side View ............... 10 Figure 4: Antenna Angle Top View ................ 10 Figure 5: Wiring Colors ..................11 AY-U9xxBT Installation and User Manual...
- Page 5 List of Tables List of Tables Table 1: Wiring the Unit as a Reader to a Control Panel ........11 AY-U9xxBT Installation and User Manual...
- Page 6 ▪ ROSSLARE exclusive warranty and liability is limited to the warranty and liability statement provided in an appendix at the end of this document. ▪...
-
Page 7: Introduction
UHF frequencies (865-868 and 902-928 MHz) and support Bluetooth BLE frequencies and protocols. Two associated apps for iOS and Android smartphones made by Rosslare – APP- x411 BLE-ID App and APP-x421 BLE-Admin App – can be used with the readers... -
Page 8: Mounting
Mounting Mounting All RFID readers can be affected by Radio Frequency Interference (RFI). For optimal read range, RFID readers should be installed away from areas with RFI. Installing an RFID reader adjacent to metallic surfaces might alter the reader’s specifications. To diminish this interference, use a plastic spacer when mounting the reader. -
Page 9: L-Shaped Stand Bracket Top-Loaded
Mounting 2.1.2 L-Shaped Stand Bracket Top-Loaded In this method, the L-shaped stand pole should have a diameter of between 60 to 80 mm (2.4 to 3.1 in.) and a height of 4.2 m (13.8 ft). The pole should be made of stainless steel with the thickness of at least 1.2 mm (0.05 in.). -
Page 10: Adjusting The Azimuth Angle Of Antenna
Mounting 2.1.3 Adjusting the Azimuth Angle of Antenna The angle of inclination with the ground plane of the antenna should be approximately 60° to 75° (Figure 3), while the deviation angle of the antenna should be biased towards the lane direction (Figure 4). Figure 3: Antenna Angle Side View Figure 4: Antenna Angle Top View AY-U9xxBT Installation and User Manual... -
Page 11: Wiring
Wiring Wiring The units are supplied with a 5 m (16.4 ft) 10-conductor pigtail with exposed wires coated with solder (see Figure 5). Figure 5: Wiring Colors To connect the unit as a reader to an access control unit: 1. Select the appropriate connections according to Table 1. 2. -
Page 12: Operation Instructions
Operation Instructions Operation Instructions After wiring the unit to a controller (POWER, GND, D0, D1), you should test the reader. To test the reader: Power up the reader. One beep is emitted and then it begins an auto-calibration procedure. After 2 seconds, the reader enters working mode. Present the appropriate type of credential to the reader. -
Page 13: Configuration With The Ble-Admin™ Application
Configuration with the BLE-Admin™ Application Configuration with the BLE-Admin™ Application Download the BLE-Admin application from Google Play or App Store using the following QR code. 2. Open the application, select the required reader from the list displayed. 3. Enter the password. NOTES: •... - Page 14 Configuration with the BLE-Admin™ Application Parameter Options Remarks Wiegand – default Transmission Protocol Select the credential output protocol OSDP 26, 32, 32R, 34, 40, 56, 64 bits Transmission Protocol To be used if Weigand Type protocol is applied Default = 26 bits OSDP Address Min = 0 To be used if OSDP protocol is...
- Page 15 Configuration with the BLE-Admin™ Application NOTE: The My BLE-ID™ application allows a mobile device to be used as a credential. Download the application from Google Play or App Store using the following: AY-U9xxBT Installation and User Manual...
-
Page 16: Technical Specifications
• EPC GEN2 (ISO18000-6C) tags Cards and Tags • BLE-ID soft credentials Note: That the reader is only compatible with Rosslare’s credentials. * Measured using a Rosslare proximity card or equivalent. ** For future use AY-U9xxBT Installation and User Manual... - Page 17 Technical Specifications Environmental Characteristics Operating Temp. Range -35°C to 60°C (-31°F to 140°F) Operating Humidity Range 0 to 95% (non-condensing) Suitable for outdoor use (IP65) Physical Characteristics Dimensions (H x W x D) AY-U915BT: 29.5 x 29.5 x 3.2 cm (11.6 x 11.6 x 1.3 in.) AY-U920BT: 36.5 x 36.5 x 3.2 cm (14.4 x 14.4 x 1.3 in.)
-
Page 18: Declaration Of Conformity
Declaration of Conformity A. Declaration of Conformity FCC ID = GCD-AYU9XXBT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: ▪ This device may not cause harmful interference. ▪ This device must accept any interference received, including interference that may cause undesired operation. -
Page 19: Radio Equipment Directive (Red)
Radio Equipment Directive (RED) Radio Equipment Directive (RED) Under our sole responsibility that the following labeled AY-U9xxBT is tested to conform to the EU Radio Equipment Directive – RED 2014/53/EU – in electrical and electronic equipment. AY-U9xxBT Installation and User Manual... -
Page 20: Rohs Directive
RoHS Directive RoHS Directive Under our sole responsibility that the following labeled AY-U9xxBT is tested to conform to the Restriction of Hazardous Substances (RoHS) directive – 2011/65/EU – in electrical and electronic equipment. AY-U9xxBT Installation and User Manual... -
Page 21: Limited Warranty
The full ROSSLARE Limited Warranty Statement is available in the Quick Links section on the ROSSLARE website at www.rosslaresecurity.com. Rosslare considers any use of this product as agreement to the Warranty Terms even if you do not review them. AY-U9xxBT Installation and User Manual... - Page 22 Fax: +86 755 8610 6101 Rosslare Security Products, Inc. support.cn@rosslaresecurity.com Southlake, TX, USA Toll Free: +1-866-632-1101 India Local: +1-817-305-0006 Fax: +1-817-305-0069 Rosslare Electronics India Pvt Ltd. support.na@rosslaresecurity.com Tel/Fax: +91 20 40147830 Mobile: +91 9975768824 Europe sales.in@rosslaresecurity.com Rosslare Israel Ltd. 22 Ha'Melacha St., P.O.B. 11407...
