Summary of Contents for Siren Marine SM-WLS3-BATT
- Page 1 Wireless Sensor Guide...
-
Page 3: Table Of Contents
Table of Contents Meet the Wireless Sensors Wireless Sensor Installation Mounting with Screws Mounting with Adhesive Strip Battery Installation Battery Replacement Pair Wireless Sensors to Main Device Bilge Pump Sensor Entry Sensor Battery Sensor High-Water Sensor Temperature Sensor Technical Specifications... -
Page 4: Meet The Wireless Sensors
Meet The Wireless Sensors Siren Marine Wireless Sensors are easy to install and ideal for hard-to-access areas. Easy to Install Peel & Stick Mounting Monitor Temperature IP67 Waterproof 2-Year Battery Life Up to 100 Foot Range... -
Page 5: Wireless Sensor Installation
The wireless sensors should be installed on a smooth flat surface. • Siren Marine adhesive strips are very strong and cannot be easily repositioned. Before you press and hold it for 30 seconds, be sure the wireless sensor is aligned correctly and is communicating... -
Page 6: Mounting With Screws
Wireless Sensor Installation Mounting with Screws: If your surfaces are rough, dirty or prone to high heat or humidity, install your wireless sensor with the supplied bracket and screws. • Remove the wireless sensor from its supplied • mounting bracket to expose the screw holes. •... -
Page 7: Mounting With Adhesive Strip
Wireless Sensor Installation Mounting with Adhesive Strip: • Make sure the surface is clean and dry. • Peel the protective cover off the adhesive strip on the back of the mounting bracket. • Align the mounting bracket in the desired position and press evenly with your palm. -
Page 8: Battery Installation
Battery Installation IMPORTANT: Your wireless sensor comes with a CR2430 internal battery which will need to be installed prior to pairing the wireless sensor with the main device. Please be sure to follow the steps below: • Attach sensor tail (if applicable to sensor type). •... -
Page 10: Battery Replacement
Battery Replacement The wireless sensor will notify you via the Siren Marine App when the internal battery voltage is low. • Remove the wireless sensor from the mounting bracket. • Remove the four screws on the back of the wireless module and remove sensor back. - Page 11 (see instructions on page 8). • Pair the wireless sensors prior to mounting in its permanent location. Go to the Settings page on the Siren Marine • App and select Add Wireless Sensor. Scan the QR Code on the back of your •...
-
Page 12: Bilge Pump Sensor
Bilge Pump Sensor Monitor bilge pump activity and receive alerts if your boat is taking on water. • There are two ways for the wireless sensor to monitor bilge pump activity: 1. Connect the positive (+) and negative (-) leads from the sensor directly to the positive (+) and negative (-) leads of your bilge pump. -
Page 14: Entry Sensor
Entry Sensor Protect against unauthorized entry. Perfect for securing lockers, doors and hatches. • Mount the Wireless Entry Sensor Mounting Bracket to a hatch, locker or other entry point. • Insert the wireless sensor battery. • Pair the Wireless Module to the main device. •... -
Page 16: Battery Sensor
Pair the Wireless Module to the main device. Secure the Wireless Battery Sensor using the • supplied Mounting Bracket. NOTE: This sensor is polarity sensitive. Notifications will be sent to the Siren Marine App if the voltage drops below or exceeds user-defined levels. -
Page 18: High-Water Sensor
Secure the water-sensing end of the tail at the desired height in the bilge using the supplied Adhesive Strip. NOTE: Notifications will be sent to the Siren Marine App if the water level in the bilge rises above the water sensor. -
Page 20: Temperature Sensor
Pair the Wireless Module to the main device (choose external if using tail, internal if not). • Secure the Wireless Temperature Sensor using the supplied Mounting Bracket. NOTE: Notifications will be sent to the Siren Marine App if the temperature falls below or exceeds the preset levels. -
Page 22: Technical Specifications
Technical Specifications Model Numbers: • Battery Sensor: SM-WLS3-BATT • Bilge Pump Sensor: SM-WLS3-BILG • Entry Sensor: SM-WLS3-ENTR • High-Water Sensor: SM-WLS3-HIWS • Temperature Sensor: SM-WLS3-TEMP Wireless Sensor Module: 2.0in (5.08cm) x 2.7in (6.9cm) x 0.6in (1.5cm) Wireless Connection: 917MHz radio frequency... - Page 23 Technical Specifications Warranty: 2-Year Limited Warranty Mounting: Mounting bracket with adhesive mounting strip and mounting screws included Requirements: Requires Siren Marine main device and Service Plan Certifications: IP67 Waterproof, FCC, EU...
- Page 24 Main Devices. Sensor compatibility is denoted on sensor packaging and on the sensor itself. For instance, wireless sensors compatible with the MTC feature just the Siren Marine logo on the front of the sensor. Wireless sensors compatible with the Siren “3” Series feature the Siren Marine logo with a superscript “3”.
