Summary of Contents for Permobil Trax
- Page 1 SERVICE MANUAL Trax...
- Page 3 800-231-3256 Email: info@permobilusa.com Head Office of the Permobil group Permobil AB Box 120 861 23 Timrå Sverige Tel: 060-59 59 00 Fax: 060-57 52 50 E-post: info@permobil.se Produced and published by Permobil AB, Sweden Edition no.3, 2010-02 Order no.: 201096-US-0...
- Page 4 Contents Contents Introduction .........................5 Technical support ......................5 Spare parts........................5 Warranties ........................5 Maintenance........................5 Rating plates........................6 Raising the seat lift ......................7 Covers ..........................8 Changing the batteries .......................10 Removal ...........................10 Fitting ..........................11 Changing the drive wheel ....................12 Changing the brake release wires..................14 Changing/adjusting the magnetic brake................16 Changing the drive motor ....................19 Removal ...........................19 Fitting ..........................21...
- Page 5 Permobil to ensure that the correct information is provided. Technical Support In the event of technical problems, you should contact your dealer, or Permobil Inc. USA at 800-736-0925. Spare parts Spare parts must be ordered through your dealer.
- Page 6 Introduction Rating plates Rear edge of Trax battery box Chassis Identity marking Chassis no. Seat lift Identity marking Seat lift...
- Page 7 Rating plates Raising the seat lift manually If the seat lift cannot be raised in the normal manner because the batteries are discharged or the adjustment device is defective, the seat can be raised manually with a 13 mm open-end spanner. NB.
- Page 8 Raising the seat lift Cover (with fixed seat tube) Removal Loosen the rear Allen screws and tip the seat forwards, see the figure to the right. Unscrew the four screws which hold the cover in place. Lift off the cover. NB.
- Page 9 Covers Cover (with seat lift) Removal Raise the seat to its highest position. If the battery is discharged, see page 6. Unscrew the four screws which hold the cover in place. Lift off the cover. NB. Be careful with the cable which goes to the rear lights.
- Page 10 Changing the batteries Changing the batteries NB. Use protective goggles when working with batteries. WARNING! First switch off the power on the manoeuvring panel before switching the power off on the main Front fuse. Clamping Removal Place the wheelchair on a level base. Battery connection, front Raise the seat to its highest position.
