REACH IN CLOSET INSTRUCTIONS
Included Plastic Parts
Tube Receivers – 5 Left & 5 Right
Read Instructions
For EZ Installation,
Installation videos:
www.ezshelf.com/videos
This Photo shows EZS-K-WRI White Reach in Closet Kit which includes 1 Closet Shelf & Rod unit (40" - 73"),
1 Closet Shelf & Rod unit (28"- 48"), 3 Shelf Units (each 28" - 48") & 3 End Brackets (1-EZS-EB-SCRW, and
2-EZS-EB-SW).
This can also be configured with the shelves on the left side.
Other layouts are possible depending upon closet measurements & your requirements.
Please call or email for design or installation assistance.
1) Measure each wall of closet before beginning and design your closet space(s).
2) Read Instructions & Watch 2 Minute Videos
The above picture has the following configuration:
Top Shelf & Rod - 1 Shelf and Rod Unit (40 – 73") – EZS-SCRW72
Bottom Shelf & Rod & Shelf – 1 Shelf & Rod Unit (28 – 48" – EZS-SCRW48) joined with
1 Shelf Unit (28 – 48" EZS-SW48) and 1 included End Bracket EZS-SW
2 Additional Shelves (28-48" EZS-SW48)_ and 2 included Shelf End Brackets (EZS-EB-SW)
Shelf units are mounted to a side wall and End Brackets are used for mounting the other side to the Back Wall.
5 Center Supports
left shown
& WATCH installation videos BEFORE beginning installation.
or email EZ@EzShelf.com
4 End Brackets – optional use
1 Shelf & Rod Unit Joined with 1
Shelf Unit with included
Shelf & Rod End Bracket
EZ-EB-SCRW
Shelf Unit Mounted to Side Wall &
Back Wall
with included 1 Shelf End Bracket
EZS-EB-SW
Advertisement
Table of Contents
Related Manuals for EZ Shelf EZS-K-WRI
Summary of Contents for EZ Shelf EZS-K-WRI
- Page 1 EZS-EB-SW This Photo shows EZS-K-WRI White Reach in Closet Kit which includes 1 Closet Shelf & Rod unit (40” - 73”), 1 Closet Shelf & Rod unit (28”- 48”), 3 Shelf Units (each 28” - 48”) & 3 End Brackets (1-EZS-EB-SCRW, and 2-EZS-EB-SW).
- Page 2 Push TIP ONLY of Anchor into drywall & Screw in plastic anchors (see drywall anchor pictures below). Use screwdriver/electric drill (on LOW setting – do NOT over tighten). Note: EZ Shelf will hold 200 lbs. WITHOUT securing to studs. Do NOT use included anchors when: ...
- Page 3 Twist both ends of tubes until fully secured. Place Center Support so the tubes rest in the slots (preferably thicker part of tubes). To make sure Center Support contacts ALL Tubes - Push center support UP from Bottom. Then Mark Holes on Back Wall. Note: DO NOT rest Center Support on...
- Page 4 White – EZS-ST-W (6 pieces for up to 73” Shelf), Silver EZS-ST-S (6 pieces for up to 73” Shelf), 1. After EZ Shelf unit has been installed, the shelf top will easily snap onto the middle tube of the unit.
