Mennekes ME 20MS1A-M2 Quick Start Manual

FOR: ME 20MS1A-M2
ME 30MS1A-M2
ME 32MS1A-M2
ME 40MS1A-M2
ME 20MS4A-M2
ME 30MS4A-M2
ME 20MS5A-M2
ME 30MS5A-M2
ME 40MS5A-M2
ME 60MS5A-M2
*If needed - pull down with screwdriver in slot. Tilt upward on load side of switch.
EQUIPMENT GROUND
TERMINAL BLOCK (GREEN/YELLOW)
FOR: ME 80MS2A-M2
ME 100MS2A-M2
*If needed - pull down with screwdriver in slot. Tilt upward on load side of switch.

Connection and Grounding

See separate conduit connection and grounding instructions.
Use above wiring diagram.

Terminal Specifications

25Amp(& 30Amp 10hp)
#10AWG
Switch
#12 to #10AWG
Ground
#14AWG
Auxiliary

WIRING DIAGRAM

HDI DISCONNECT SWITCHES
Auxiliary Contact
L L 1 1
1 1 3 3
OFF
1 1 4 4
T T 1 1
EQUIPMENT GROUND TERMINAL BLOCK (GREEN/YELLOW)
L L 1 1
43
31
OFF
32
44
T T 1 1
AUXILIARY CONTACT BLOCK
Torque
13-16 lbs./in.
20 lbs./in.
4 lbs./in.
Auxiliary Contact
L L 2 2 L L 3 3
ON
2 2 1 1
2 2 2 2
T T 3 3
T T 2 2
RELEASE MECHANISM*
L L 2 2 L L 3 3
ON
T T 2 2 T T 3 3
RELEASE MECHANISM*
30, 40 & 60 Amp Torque
#10 to #6AWG 20-24 lbs./in.
#10 to #8AWG 20 lbs./in.
#12AWG 7 lbs./in.
CONTACT ARRANGEMENT
L L 1 1 L L 2 2 L L 3 3
1 1 3 3 2 2 1 1
1 1 4 4 2 2 2 2
T T 2 2 T T 3 3
T T 1 1
AUXILIARY CONTACTS
Rating: 10A 600Vac
Wiring: 13-14 N/O
21-22 N/C
CONTACT ARRANGEMENT
L L 1 1 L L 2 2 L L 3 3
43 43
31 31
44 44
32 32
T T 1 1 T T 2 2 T T 3 3
AUXILIARY CONTACTS
Rating: 10A 600Vac
Wiring: 43-44 N/O
31-32 N/C
.
80 & 100 Amp Torque
#6 to #2AWG
22-27 lbs./in.
#8 to #6AWG
20 lbs./in.
#12AWG
7 lbs./in.
